Acer Aspire 300W PSU PS-6301-08A3

We apologize but this item is currently unavailable. Please feel free to browse our website for other available items.
Acer Aspire 300W Psu Ps-6301-08A3. Model: Ps-6301-08A Dc.3001B.001
  Enlarge
Acer Aspire 300W Psu Ps-6301-08A3. Model: Ps-6301-08A Dc.3001B.001
Acer Aspire 300W Psu Ps-6301-08A3. Model: Ps-6301-08A Dc.3001B.001
*Note this image is for descriptional purposes.
Actual product may vary.
Item Code PSLITPS630108A3
Brand Liteon Corp.
Model PS-6301-08A DC.3001B.001
Category House Brand Power Supplies
Condition Pre-Owned Grade B
Condition Description Please note, this item is used and has minor scuffs and scratches!

Description

Acer Aspire ATC-280 ATC-605 ATC-705 Series 300W 100-127Vac/ 200-240Vac 50-60Hz 7A/ 3.5A 24-Pin Desktop ATX12V PSU Power Supply Unit PS-6301-08A PS-6301-08A3.

Liteon Model Number: PS-6301-08A PS-6301-08A3
Compatible Part Numbers: DC3001B001 DC.3001B.001
Compatible Models: Acer Aspire ATC-280-UR11 ATC-605-UR2S ATC-705-UC52 ATC-705-UR42 ATC-705-UR53 ATC-705-UR54 ATC-705-UR55 ATC-705-UR56 ATC-705-UR58 ATC-705-UR5A ATC-705-UR5B




Specifications:

Power Supply Type: ATX12V
Total Max Wattage: 300W
Input Voltage: 100-127Vac (7A) / 200-240Vac (3.5A)
Input Frequency Range: 50-60Hz
Output: +5V(20A), -12V(0.5A), +12V1(10A), +5VSB(2A), +3.3V(20A) +12V2(13A)
Connector(s):
1 x 24-Pin ATX System Board Connector
1 x 4-Pin ATX +12V Motherboard Power Connector
1 x 4-Pin Peripheral Power Connector
1 x 4-Pin Floppy Drive Power Connector
4 x 15-Pin SATA Power Connector
