AMD ATI Firepro V5800 1GB VC 608530-002

AMD ATI FirePro V5800 1GB GDDR5 PCI-E 2.0 x16 DP-DVI Dual DisplayPort Desktop 3D Graphics Video Card 608530-002 608888-001.

ATI Model Number: FirePro V5800
HP Part Number: 608530-002
Compatible Part Numbers: 608888-001







Features:

Image Quality Features:
- 3 independent outputs with ATI Eyefinity technology support
- Full 30-bit display pipeline for more accurate color reproduction superior image quality
- Advanced video capabilities, including high fidelity gamma, color correction and scaling
- Dedicated hardware (UVD2) for H.264, VC-1, and MPEG2 decode

Shading Architecture:
- Support for Full Shader Model 5.0
- Dynamic load balancing and resource allocation for vertex, geometry, and pixel shaders
- Common instruction set and texture unit access supported for all types of shaders
- Dedicated branch execution units and texture address processors
- Anti-aliases Shaders and Textures as well as Polygon Edges







Specifications:

Memory:
- Memory Size: 1GB
- Memory Type: GDDR5
Bus Interface:
- PCIe 2.0 x16
RAMDAC:
- 400 MHz DAC, 10-bits per channel
API Supported:
- DirectX 11
- OpenGL 3.2
- OpenCL 1.0
- DirectCompute 11
Output:
- 2x Displayport
- 1x DVI-I
Mounting:
- 1x Full-Height bracket
- 1x Rear bracket
