ASUS P5G41-M LE DDR2 LGA775 G41 SATA DVI

This ASUS P5G41-M LE motherboard supports the latest Intel Core 2 processors in LGA775 package. It also can support Intel 45nm Multi-Core CPU. With new Intel Core microarchitecture technology and 1333/1066/800MHz FSB, Intel Core2 processor is one of the most powerful and energy efficient CPU in the world.



Specifications:

CPU:
Intel Socket 775 Core2 Extreme/Core2 Duo/Pentium dual-core/Celeron dual-core /Celeron Processors
Support Intel 45nm Multi-Core CPU

Chipset:
Intel G41 /ICH7

Front Side Bus:
1333/1066/800 MHz

Memory:
2 x240-pin DIMM, Max. 8 GB, DDR2 1066(O.C.)/800/667 Non-ECC,Un-buffered Memory
Dual Channel memory architecture

Expansion Slots:
1 x PCIe x16
1 x PCIe x1
2 x PCI

VGA:
Integrated Intel Graphics Media Accelerator (Intel GMA X4500)
- Supports RGB with max. resolution 2048 x 1536 @ 75Hz
- Supports Microsoft DirectX 10

Storage:
Southbridge
1 xUltraDMA 100
4 xSATA 3 Gb/s ports

LAN:
PCIe Gb LAN

Audio:
High Definition Audio 6-Channel CODEC
Supports Jack-detect and Multi-Streaming teconologies
Supports S/PDIF out interface

USB:
8 USB 2.0/1.1 ports (4 ports at mid-board, 4 ports at back panel)

Overclocking Features:
SFS (Stepless Frequency Selection)
- FSB tuning from 200MHz to 800MHz at 1MHz increment
Overclocking Protection
- ASUS C.P.R.(CPU Parameter Recall)

Special Features:
ASUS MyLogo 2
ASUS EZ Flash 2
ASUS CrashFree BIOS 3
ASUS Q-Fan
Turbo Key
ASUS EPU-L
Anti-Surge
AI NET2

Back Panel I/O Ports:
1 x DVI
1 x VGA
1 x PS/2 Keyboard
1 x PS/2 Mouse
1 x LAN(RJ45) port
4 x USB 2.0/1.1
6 -Channel Audio I/O

Internal I/O Connectors:
2 x USB connectors support additional 4 USB 2.0 ports
1 x IDE connector
4 x SATA connectors
1 x CPU Fan connector
1 x Chassis Fan connector
1 x High Definition front panel audio connector
1 x S/PDIF output connector
1 x System Panel connector
1 x Internal Speaker connector
1 x LPT Connector (must have the cable)
1 x COM Connector (must have the cable)
24-pin EATX power connector
4-pin ATX 12V Power connector

BIOS:
8 Mb Flash ROM AMI BIOS, PnP, DMI2.0, WfM2.0, ACPI2.0, SMBIOS 2.5

Form Factor:
uATX Form Factor
9.6 inch x 7.8 inch ( 24.4 cm x 19.8 cm )





CPU Support List:

Celeron 420(1.60GHz,800 FSB,L2 512KB,LGA775,revA1)

Celeron 430(1.80GHz,800 FSB,L2 512KB,LGA775,revA1)

Celeron 450(2.2GHz,800 FSB,L2 512KB,LGA775,revA1)

Celeron Dual Core E1200(revM0,1.6GHz,800 FSB,L2:512K)

Celeron Dual Core E1400 (revM0,2.0GHz, 800 FSB, L2: 512K)

Celeron Dual Core E1600(revM0,2.4GHz,800 FSB,L2: 512K)

Celeron Dual Core E3200(revR0,2.4GHz,800 FSB,L2: 1M) 1.01G

Celeron Dual Core E3300(revR0,2.5GHz,800 FSB,L2: 1M) 1.01G

Celeron Dual Core E3400(revR0,2.6GHz,800 FSB,L2: 1M)

Celeron Dual Core E3500(revR0,2.7GHz,800 FSB,L2: 1M)

Core 2 Duo E4300 (1.8GHz,800FSB,L2:2MB,65W,rev.L2)

Core 2 Duo E4400 (2.0GHz,800FSB,L2:2MB,65W,rev.M0)

Core 2 Duo E4500 (2.2GHz,800FSB,L2:2MB,65W,rev.M0)

Core 2 Duo E4600 (2.4GHz,800FSB,L2:2MB,65W,rev.M0)

Core 2 Duo E4700 (2.6GHz,800FSB,L2:2MB,revG0)

Core 2 Duo E6300 (1.86GHz,1066FSB,L2:2MB,rev.L2)

Core 2 Duo E6320 (1.86GHz,1066FSB,L2:4MB,rev.B2)

Core 2 Duo E6400 (2.13GHz,1066FSB,L2:2MB,rev.L2)

Core 2 Duo E6540 (2.33GHz,1333FSB,L2:4MB,rev.G0)

Core 2 Duo E6550 (2.33GHz,1333FSB,L2:4MB,rev.G0)

Core 2 Duo E6750 (2.66GHz,1333FSB,L2:4MB,rev.G0)

Core 2 Duo E6850 (3.00GHz,1333FSB,L2:4MB,rev.G0)

Core 2 Duo E7200(2.53GHz,1066FSB,L2:3MB,rev.M0)

Core 2 Duo E7300(2.66GHz,1066FSB,L2:3MB,rev.M0)

Core 2 Duo E7400(2.80GHz,1066FSB,L2:3MB,rev.R0)

Core 2 Duo E7500(2.93GHz,1066FSB,L2:3MB,rev.R0)

Core 2 Duo E7600(3.06GHz,1066FSB,L2:3MB,rev.R0)

Core 2 Duo E8190(2.66GHz,1333FSB,L2:6MB,rev.C0)

Core 2 Duo E8200 (2.66GHz,1333FSB,L2:6MB,rev.C0)

Core 2 Duo E8300 (2.83GHz,1333FSB,L2:6MB,rev.C0)

Core 2 Duo E8400 (3.00GHz,1333FSB,L2:6MB,65W,rev.E0)

Core 2 Duo E8400 (3.00GHz,1333FSB,L2:6MB,rev.C0)

Core 2 Duo E8500 (3.16GHz,1333FSB,L2:6MB,65W,rev.E0)

Core 2 Duo E8500 (3.16GHz,1333FSB,L2:6MB,rev.C0)

Core 2 Duo E8600 (3.33GHz,1333FSB,L2:6MB,65W,rev.E0)

Core 2 Extreme QX6800 (rev.G0,2.93GHz,1066FSB,L2:2X4MB,4 cores)

Core 2 Extreme QX6850(revG0,3.00GHz,1333FSB,L2:2X4MB)

Core 2 Extreme QX9650 (rev.C1,3.00GHz,1333FSB,L2:2X6MB,4 cores)

Core 2 Extreme QX9650(revC0,3.00GHz,1333FSB,L2:2X6MB)

Core 2 Extreme QX9770(revC1,3.2GHz,1600FSB,L2:2X6MB)

Core 2 Quad Q6600 (2.40GHz,1066FSB,L2:2X4MB,rev.G0,4 cores)

Core 2 Quad Q6700 (2.66GHz,1066FSB,L2:2X4MB,rev.G0,4 cores)

Core 2 Quad Q8200 (rev.M1,2.33GHz,1333FSB,L2:4MB,4 cores)

Core 2 Quad Q8200 (rev.R0,2.33GHz,1333FSB,L2:4MB,4 cores)

Core 2 Quad Q8200S (rev.R0,2.33GHz,1333FSB,L2:4MB,4 cores)

Core 2 Quad Q8300 (rev.R0,2.50GHz,1333FSB,L2:4MB,4 cores)

Core 2 Quad Q8400 (rev.R0,2.66GHz,1333FSB,L2:4MB,4 cores)

Core 2 Quad Q8400S (rev.R0,2.66GHz,1333FSB,L2:4MB,4 cores)

Core 2 Quad Q9300 (2.5GHz,1333FSB,L2:6MB,rev.M0,4 cores)

Core 2 Quad Q9300 (2.5GHz,1333FSB,L2:6MB,rev.M1,4 cores)

Core 2 Quad Q9400 (rev.R0,2.66GHz,1333FSB,L2:6MB)

Core 2 Quad Q9400S (rev.R0,2.66GHz,1333FSB,L2:6MB)

Core 2 Quad Q9450 (2.66GHz,1333FSB,L2:12MB,rev.C1)

Core 2 Quad Q9500 (2.83GHz,1333FSB,L2:6MB,rev.R0)

Core 2 Quad Q9505(rev.R0,2.83GHz,1333FSB,L2:6MB) 1.01G

Core 2 Quad Q9550(2.83GHz,1333FSB,L2:12MB,rev.C1)

Core 2 Quad Q9550(rev.C0,2.83GHz,1333FSB,L2:12MB)

Core 2 Quad Q9550(rev.E0,2.83GHz,1333FSB,L2:12MB)

Core 2 Quad Q9550S(rev.E0,2.83GHz,1333FSB,L2:12MB)

Core 2 Quad Q9650(rev.E0,3.00GHz,1333FSB,L2:12MB)

Pentium Dual Core E2140(1.6GHz,800FSB,L2 1MB,M0)

Pentium Dual Core E2160(1.8GHz, 800FSB, L2 1MB,L2)

Pentium Dual Core E2160(1.8GHz,800FSB,L2 1MB,M0)

Pentium Dual Core E2180(2.0GHz,800FSB,L2 1MB,M0)

Pentium Dual Core E2200(2.2GHz,800FSB,L2 1MB,M0)

Pentium Dual Core E2210(2.2GHz,800FSB,L2 1MB,R0)

Pentium Dual Core E2220(2.4GHz,800FSB,L2 1MB,M0)

Pentium Dual Core E5000 (3.4GHz,800FSB,L2:2MB,rev.R0)

Pentium Dual Core E5200 (2.50GHz,800FSB,L2:2MB,rev.M0)

Pentium Dual Core E5200(2.50GHz,800FSB,L2:2MB,rev.R0)

Pentium Dual Core E5300 (2.60GHz,800FSB,L2:2MB,rev.R0)

Pentium Dual Core E5400 (2.70GHz,800FSB,L2:2MB,rev.R0)

Pentium Dual Core E5500 (2.8GHz,800FSB,L2:2MB,rev.R0)

Pentium Dual Core E5700 (3.0GHz,800FSB,L2:2MB,rev.R0)

Pentium Dual Core E5800 (3.2GHz,800FSB,L2:2MB,rev.R0)

Pentium Dual Core E6300 (2.8GHz,1066FSB,L2:2MB,rev.R0)

Pentium Dual Core E6500 (2.93GHz,1066FSB,L2:2MB,rev.R0) 1.01G

Pentium Dual Core E6600 (3.06GHz,1066FSB,L2:2MB,rev.R0)

Pentium Dual Core E6700 (3.2GHz,1066FSB,L2:2MB,rev.R0)

Pentium Dual Core E6800 (3.3GHz,1066FSB,L2:2MB,rev.R0)
