ASUS P5PL2-E LGA775 945P/G Motherboard

ASUS P5PL2-E LGA 775 Intel 945PL Express ATX Intel Motherboard. This motherboard supports the latest Pentium 4 CPU from Intel in LGA775 package. With 1066/ 800/ 533MHz FSB, Hyper-Threading Technology and core-speeds up to 3.8GHz and beyond.





Specifications:

CPU:
Intel Socket 775 Processors
Prescott/Smithfield/Cedermill/Presler/Conroe/CPU
Support Intel@ next generation 65nm(both Single & Dual Core) CPU
Support Intel@ EM64T/EIST/Hyper-Threading TechnologyU

Chipset:
Intel 945P/G
Intel ICH7

Front Side Bus:
1066/800/533 MHz

Memory:
4 x DIMM, Max. 2 GB, DDR2 533/400 Non-ECC,Un-buffered Memory
Dual Channel memory architecture

Expansion Slots:
1 x PCIe x16
2 x PCIe x1
3 x PCI 2.2

Storage:
Southbridge
1 xUltraDMA 100/66/33
4 xSATA 1 Gb/s ports

Audio:
Azalia CODEC: ADI1986A 6 -Channel High Definition Audio
S/PDIF out on back I/O port
Supports Jack Sensing & Enumeration

LAN:
RTL8111B PCI-E Gigabit LAN controller

Overclocking Features:
Intelligent overclocking tools
- ASUS PEG Link
Precision Tweaker
- vDIMM: 4 -step DRAM voltage control
- vCore: Adjustable CPU voltage at 0.0125V increment
SFS (Stepless Frequency Selection)
- FSB tuning from 100MHz up to 450MHz at 1MHz increment
Overclocking Protection
- ASUS C.P.R.(CPU Parameter Recall)
Adjustable FSB/DDR ratio. Fixed PCI/PCIe frequencies
4-step DRAM voltage control

USB:
8 USB 2.0 ports
Special Features
ASUS MyLogo
ASUS EZ Flash
ASUS Q-Fan

Back Panel I/O Ports:
1 x Parallel
1 x PS/2 Keyboard
1 x PS/2 Mouse
1 x Serial port
1 x S/PDIF Out
1 x LAN(RJ45) port
4 x USB 2.0/1.1
6 -Channel Audio I/O

Internal I/O Connectors:
2 x USB connectors supports additional 4 USB ports
1 x CPU Fan connector
1 x Chassis Fan connector
1 x Power Fan connector
1 x S/PDIF Out connector
1 x4-pin ATX 12V Power connector
24 -pin ATX Power connector
Front panel audio connector
Game/MIDI port connector
Chassis Intrusion connector
CD/AUX audio in

BIOS:
4 Mb Flash ROM
DMI
AMI BIOS
PnP
WfM 2.0
SM BIOS 2.3
ASUS EZ Flash
ASUS MyLogo
ASUS CrashFree BIOS 2

Manageability:
WOL/WOR by PME，WOR by Ring， ,WO_USB, WO_KB/MS WOW

Form Factor:
ATX Form Factor
12 inch x 7.5 inch ( 30.5 cm x 19 cm )
