Asus P5QL-VM EPU CM5570 Motherboard

Asus P5QL-VM EPU LGA775 G43 DDR2 Motherboard. This motherboard supports the latest Intel 45nm CPU which introduces new micro-architecture features for greater performance at a given frequency, up to 50% larger L2 caches, and expanded power management capabilities for new levels of energy efficiency. This motherboard supports the latest Intel® Core™2 processors in LGA775 package. It also can support Intel® next generation 45nm Multi-Core CPU. With new Intel® Core™ microarchitecture technology and 1333 / 1066 / 800 MHz FSB, Intel® Core™2 processor is one of the most powerful and energy efficient CPU in the world.



* Please Note: This is an OEM motherboard and it does not come with rear I/O shield also known as back-plate cover. This part is not needed and you can still install the board in standard ATX case.

Specifications:

CPU
Intel® Socket 775 Core™2 Quad/Core™2 Extreme/Core™2 Duo/Pentium® dual-core Support Intel® 45nm CPU
Intel® Hyper-Threading Technology ready
Support Enhanced Intel SpeedStep Technology (EIST)

Chipset
Intel® G43 / ICH10

Front Side Bus
1333/1066/800 MHz

Memory
4 x DIMM, Max. 16 GB, DDR2 1066(O.C.)/800/667 Non-ECC,Un-buffered Memory
Dual Channel memory architecture

Expansion Slots
1 x PCIe 2.0 x16
1 x PCIe 2.0 x1
2 x PCI

VGA
Integrated Intel GMA X4500 graphics
Maximum shared memory of 1759M
Supports DVI-D with HDCP compliant with max. resolution 1920x1200 (@ 60Hz)
Supports HDMI with max. resolution 1920X1080(@ 60Hz)
Supports RGB with max. resolution 2048 x 1536 (@75Hz)
Supports Microsoft® DirectX® 10
Dual VGA output support:
DVI & HDMI
DVI & RGB
RGB & HDMI

Storage
Southbridge
6 x SATA 3 Gb/s ports
1 x UltraDMA 133/100
JMicron® JMB368 PATA controller

LAN
RTL8112 PCIe Gb LAN

Audio
ALC887 8 -Channel High-Definition Audio CODEC
Optical S/PDIF output
Support Jack Detection and Multi-streaming

USB Ports
12 USB 2.0 ports (6 ports at mid-board, 6ports at back panel)

BIOS
8 Mb Flash ROM
AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.5, ACPI 2.0a

Back Panel I/O Ports
1 x DVI
1 x D-Sub
1 x PS/2 Keyboard
1 x HDMI
1 x S/PDIF Out (optical)
1 x LAN(RJ45) port
6 x USB 2.0/1.1
8 -Channel Audio I/O

Internal I/O Connectors
3 x USB connectors (6ports)
1 x IDE connector
1 x CPU Fan connector
1 x Chassis Fan connector
1 x Power Fan connector
1 x S/PDIF Out connector
Front panel audio connector
COM connector
System Panel connector
1 x LPT connector
CD audio in
1 x 24-pin EPS12V Power connector
4-pin ATX 12V Power connector

Form Factor
uATX Form Factor
9.6 inch x 8.8 inch ( 24.4 cm x 22.4 cm )
