ASUS P7P55 LX P55 LGA1156 DDR3 SATA2 USB

Asus P7P55 LX Motherboard - LGA 1156, Intel P55, SATA, SLI Ready, CrossFireX Ready, Dual Channel DDR3 support, RAID, Hyperthreading support. Based on the Intel LGA1156/Intel P55 Express Chipset, the P7P55 LX supports Quad-GPU CrossFireX, DDR2 3300 (O.C.), ASUS TurboV, and MemOKI! The Asus P7P5 LX Intel LGA 1156 motherboard supports the latest Intel Lynnfield processors in LGA1156 package which has memory and PCI Express controller integrated to support 2-channel (4 DIMMs) DDR3 memory and 16 PCI Express 2.0 lanes providing great graphics performance. Intel Lynnfield processor is one of the most powerful and energy efficient CPU in the world.

Specifications:

CPU:
Intel Socket 1156 Core i7/Core i5 Processors
Supports Intel Turbo Boost Technology

Chipset:
Intel P55

Memory:
4 x DIMM, Max. 16GB, DDR3 2200(O.C.)/1600/1333/1066 Hz Non-ECC, Un-buffered Memory
Dual Channel Memory Architecture
Supports Intel Extreme Memory Profile (XMP)

Multi-GPU Support:
Supports AMD Quad-GPU CrossFireX Technology

Expansion Slots:
1 x PCIe 2.0 x16
1 x PCIe 2.0 x16 (x4 mode, 2.5 GT/s)
2 x PCIe 2.0 x1 (2.5 GT/s)
3 x PCI

Storage:
Intel P55 chipset :
6 x SATA 3Gb/s port(s), blue
Support Raid 0, 1, 5, 10
VIA VT6415 controller :
1 x UltraDMA 133/100/66 for up to 2 PATA devices , navy blue

LAN:
Realtek 8112L, 1 x Gigabit LAN Controller(s), featuring AI NET2

Audio:
VIA VT1708S 8-Channel High Definition Audio CODEC
- Supports : Jack-detection, Multi-streaming
Audio Feature :
- ASUS Noise Filter
- Optical S/PDIF out port(s) at back panel

USB Ports:
Built-in Controller :
14 x USB 2.0 port(s) (8 at back panel, black, 6 at mid-board)

Overclocking Features:
Overclocking Protection :
- ASUS C.P.R.(CPU Parameter Recall)

Special Features:
ASUS EPU :
- EPU
Turbo Key
TurboV
ASUS Exclusive Features :
- MemOK!
- Express Gate
ASUS Quiet Thermal Solution :
- Stylish Fanless Design Heat-sink solution
- ASUS Fan Xpert
ASUS EZ DIY :
- ASUS O.C. Profile
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 2
- ASUS MyLogo 2
- Multi-language BIOS
ASUS Q-Design :
- ASUS Q-DIMM

Back I/O Ports:
1 x PS/2 keyboard (purple)
1 x PS/2 mouse (green)
1 x LAN (RJ45) port(s)
8 x USB 2.0
1 x Optical S/PDIF out
6 x Audio jack(s)

Internal I/O Ports:
3 x USB 2.0 connector(s) support(s) additional 6 USB 2.0 port(s)
1 x IDE connector(s)
1 x COM port(s) connector(s)
6 x SATA 3Gb/s connector(s)
1 x CPU Fan connector(s)
1 x Chassis Fan connector(s) (1 x 4 -pin, 1 x 3 -pin)
1 x S/PDIF out header(s)
1 x 24-pin EATX Power connector(s)
1 x 4-pin ATX 12V Power connector(s)
1 x Front panel audio connector(s) (AAFP)
1 x CD audio in(s)
1 x System panel(s)
1 x MemOK! button(s)

BIOS:
16 Mb Flash ROM , AMI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.5, ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS 3

Manageability:
WfM 2.0,DMI 2.0,WOL by PME,WOR by PME,PXE

Form Factor:
ATX Form Factor
12 inch x 8.6 inch ( 30.5 cm x 21.8 cm )




CPU Support List:

Core i3 530(2.93G,L2:4M, IGPU,rev.C2,73W)

Core i3 530(2.93G,L2:4M, IGPU,rev.K0,73W)

Core i3 540(3.06G,L2:4M,IGPU, rev.C2,73W)

Core i3 540(3.06G,L2:4M,IGPU, rev.K0,73W)

Core i3 550(3.2G,L2:4M, IGPU,rev.K0)

Core i3 560(3.33G,L2:4M, IGPU,rev.K0)

Core i5 650(3.2G,L2:4M, IGPU,rev.C2,73W)

Core i5 650(3.2G,L2:4M, IGPU,rev.K0,73W)

Core i5 655K(3.2G,L2:4M, IGPU,rev.K0,73W)

Core i5 660(3.33G,L2:4M, IGPU,rev.C2,73W)

Core i5 660(3.33G,L2:4M, IGPU,rev.K0,73W)

Core i5 661(3.33G,L2:4M,IGPU, rev.C2,87W)

Core i5 661(3.33G,L2:4M,IGPU, rev.K0,87W)

Core i5 670(3.46G,L2:4M, IGPU,rev.C2,73W)

Core i5 670(3.46G,L2:4M, IGPU,rev.K0,73W)

Core i5 680(3.6G,L2:4M, IGPU,rev.K0,73W)

Core i5 750(2.66G,L3:8M, rev.B1,95W)

Core i5 750S(2.4G,L3:8M, rev.B1,82W)

Core i5 760(2.8G,L3:8M, rev.B1,95W)

Core i7 860(2.80G,L3:8M, rev.B1,95W)

Core i7 860S(2.53G,L3:8M, rev.B1,82W)

Core i7 870(2.93G,L3:8M, rev.B1,95W)

Core i7 870S(2.66G,L3:8M, rev.B1)

Core i7 875K(2.93G,L3:8M, rev.B1,)

Core i7 880(3.06G,L3:8M, rev.B1)

Pentium G6950(2.8G,L2:4M, IGPU,rev.C2,73W)

Pentium G6950(2.8G,L2:4M, IGPU,rev.K0,73W)

Pentium G6960(2.93G,L2:3M, IGPU,rev.K0,73W)
