ASUS P9X79 DELUXE LGA2011 X79 DDR3 WIFI

ASUS P9X79 DELUXE LGA 2011 Intel X79 SATA 6Gb/s USB 3.0 ATX Intel Motherboard with UEFI BIOS. The ASUS exclusive Dual Intelligent Processors 3 technology with DIGI+ Power control enables enhanced performance, stability, and overclocking capability for your CPU and RAM. It allows for consistent power delivery to achieve a higher level of performance on the X79 platform. The ASUS P9X79 DELUXE Intel X79 Motherboard motherboard is ready for PCIe 3.0 technology when integrating high-end GPU's and future PCIe 3.0 peripherals. It also has multi-GPU support for installing multiple graphics cards.



Specifications:

CPU:
Intel Socket 2011 for 2nd Generation Core i7 Processors
Supports Intel Turbo Boost Technology 2

Chipset:
Intel X79

Memory:
8 x DIMM, Max. 64GB, DDR3 2400(O.C.)/2133(O.C.)/1866/1600/1333/1066 MHz Non-ECC, Un-buffered Memory
Quad Channel Memory Architecture
Supports Intel Extreme Memory Profile (XMP)

Multi-GPU Support:
Supports NVIDIA 3-Way SLI Technology
Supports AMD Quad-GPU CrossFireX Technology

Expansion Slots:
3 x PCIe 3.0/2.0 x16 (dual x16 or x16, x8, x8)
1 x PCIe 3.0/2.0 x16 (x8 mode)
2 x PCIe 2.0 x1

Storage:
Intel X79 chipset :
2 x SATA 6Gb/s port(s), white
4 x SATA 3Gb/s port(s), blue
Support Raid 0, 1, 5, 10
Marvell PCIe 9128 controller :
2 x SATA 6Gb/s port(s), white
ASMedia ASM1061 controller :
2 x Power eSATA 6Gb/s port(s), green

LAN:
Realtek 8111E , 1 x Gigabit LAN Controller(s)
Intel 82579V, 1 x Gigabit LAN Controller(s)
Dual Gigabit LAN controllers- 802.3az Energy Efficient Ethernet (EEE) appliance

Wireless Data Network:
Wi-Fi 802.11 b/g/n

Bluetooth:
Bluetooth V3.0+HS
ASUS BT GO! Utility

Audio:
Realtek ALC898 8-Channel High Definition Audio CODEC
- Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking
Audio Feature :
- Absolute Pitch 192kHz/ 24-bit True BD Lossless Sound
- Blu-ray audio layer Content Protection
- DTS Ultra PC II
- DTS Connect
- Optical S/PDIF out port(s) at back panel

USB Ports:
ASMedia USB 3.0 controller :
8 x USB 3.0 port(s) (6 at back panel, blue, 2 at mid-board)
Intel X79 chipset :
12 x USB 2.0 port(s) (4 at back panel, black+white, 8 at mid-board)

Special Features:
ASUS Dual Intelligent Processors 3 with New DIGI+ Power Control :
ASUS TPU :
- Auto Tuning
- TurboV
- TPU switch
ASUS EPU :
- EPU
- EPU switch
ASUS Digital Power Design :
- Industry leading Digital 16 + 4 Phase CPU Power Design
- Industry leading Digital 2 + 2 Phase DRAM Power Design
- CPU Power Utility
- DRAM Power Utility
ASUS BT GO! :
- Folder Sync
- BT Transfer
- Shot & Send
- BT to Net
- Music Player
- Personal Manager
ASUS BT Turbo Remote :
- Exclusive Smartphone Interface supporting iPhone, Android, Windows Mobile, and Symbian systems
ASUS Exclusive Features :
- MemOK!
- AI Suite II
- Ai Charger
- ASUS UEFI BIOS EZ Mode featuring friendly graphics user interface
- ASUS SSD Caching
- USB 3.0 Boost
ASUS Quiet Thermal Solution :
- Stylish Fanless Design Heat-pipe solution
- ASUS Fan Xpert+
ASUS EZ DIY :
- USB BIOS Flashback
- ASUS Q-Shield
- ASUS O.C. Profile
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 2
- ASUS MyLogo 2
- Multi-language BIOS
ASUS Q-Design :
- ASUS Q-Code
- ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)
- ASUS Q-Slot
- ASUS Q-DIMM
- ASUS Q-Connector

Back I/O Ports:
1 x Bluetooth module(s)
2 x Power eSATA 6Gb/s
2 x LAN (RJ45) port(s)
6 x USB 3.0
4 x USB 2.0 (one port can be switched to USB BIOS Flashback)
1 x Optical S/PDIF out
6 x Audio jack(s)
1 x Wi-Fi antenna port(s)
1 x USB BIOS Flashback Button(s)

Internal I/O Ports:
1 x USB 3.0 connector(s) support(s) additional 2 USB 3.0 port(s) (19-pin)
4 x USB 2.0 connector(s) support(s) additional 8 USB 2.0 port(s)
4 x SATA 6Gb/s connector(s)
4 x SATA 3Gb/s connector(s)
1 x CPU Fan connector(s) (4 -pin)
4 x Chassis Fan connector(s) (4 -pin)
1 x Optional Fan connector(s) (4 -pin)
1 x S/PDIF out header(s)
1 x 24-pin EATX Power connector(s)
1 x 8-pin ATX 12V Power connector(s)
1 x Front panel audio connector(s) (AAFP)
1 x System panel(s) (Q-Connector)
1 x MemOK! button(s)
1 x TPU switch(es)
1 x EPU switch(es)
1 x Power-on button(s)
1 x Reset button(s)
1 x Clear CMOS jumper(s)
1 x Bluetooth v3.0 + HS header(s)

BIOS:
64 Mb Flash ROM, UEFI BIOS, PnP, DMI2.0, WfM2.0, SM BIOS 2.6, ACPI 2.0a, Multi-language BIOS, ASUS EZ Flash 2, ASUS CrashFree BIOS 3

Manageability:
WfM 2.0, DMI 2.0, WOL by PME, WOR by PME, PXE

Form Factor:
ATX Form Factor
12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )






CPU Support List:

Core i7-3820 (3.6G,L3:10M,6C,HT,rev.M0)

Core i7-3820 (3.6G,L3:10M,6C,HT,rev.M1)

Core i7-3930K (3.2G,L3:12M,6C,HT,rev.C1)

Core i7-3930K (3.2G,L3:12M,6C,HT,rev.C2)

Core i7-3960X Extreme Edition(3.3G,L3:15M,6C,HT,rev.C1)

Core i7-3960X Extreme Edition(3.3G,L3:15M,6C,HT,rev.C2)

Core i7-3970X Extreme Edition(3.5G,L3:15M,6C,HT,150W,rev.C2)
