AZZA CSAZ-GT 1 Black SECC ATX Full Tower

Model

Brand

AZZA

Model

CSAZ-GT 1

Details

Type

ATX Full Tower

Color

Black

Case Material

SECC

With Power Supply

No

Power Supply Mounted

Bottom

Motherboard Compatibility

Micro ATX / ATX / E-ATX / XL-ATX

Side Panel Window

Yes

Expansion

External 5.25" Drive Bays

9

Internal 3.5" Drive Bays

7

Hot-Swap Drive Bays

Easy Swap 2.5" SSD Slot : 1(5 option)
Easy Swap 3.5" HDD Slot: 1(5 option)

Expansion Slots

9

Front Panel Ports

Front Ports

2 x USB 3.0 / 2 x USB 2.0 / Audio

Cooling System

90mm Fans

1 x 90mm Blue lED fan in the front

120mm Fans

1 x 120mm Fan in Rear, 1x120mm on The Side for HDD

140mm Fans

1 x 140mm Silent Fan(19DBA)

230mm Fans

1 x 230mm Blue LED Silent Fan(24DBA)

Dimensions & Weight

Max GPU Length Allowance

400 mm

Max CPU Cooler Height Allowance

200 mm

Dimensions (H x W x D)

24.40" x 9.80" x 23.20"

Weight

30.00 lbs.

Additional Info

Features

Optimum Cooling for GPU:
Reversible motherboard tray available to turn 180 degree to
locate VGA card on the top, placing it next to the top fan to
enhance the efficiency of heat dissipation.

Ideal Aero dynamical Airflow:
An ideal vertical airflow is generated to offer supreme system
cooling: with the power supply installed in the front bottom,
1x140mm stock fans located in the mid- and rear bottom
deliver gusts of winds blowing upward with the heat exhausted
via the 1x230mm top fan.

Exceptional Cooling System:
Total 4 fans
1x230mm fan locate on top, exhaust the hot air out
1x140mm fan located on the bottom intake the cool air
1x120mm fan located on side panel for cool HDD
1x120mm fan locate in the rear, exhaust the hot air out

Easy Swap Slot for 3.5" HDD and 2.5” SSD:
1x Easy Swap HDD tray(option 5) for easy install HDD, no
need to un-screw any screw to install HDD

Maximum Capacity water cooler:
Support 1x480mm plus 1x240mm and 1x120mm water cooling
radiators.

Support longest VGA card:
Accommodate VGA card up to 400mm

USB 3.0 Ready: 2xUSB 3.0, 2xUSB 2.0

Maximum Compatibility:
Accommodate XL-ATX, E-ATX, Full ATX, Micro ATX and
all kind of Nvdia, ATI long VGA card up to 400mm. And all kinds
Of water cooling system and support up to 480mm radiator.

Easy install CPU cooler a: cut off hole for easy install CPU cooler no need to take out motherboard.
