Cisco 1800 Model 1841 Integrated Router
We apologize but this item is currently unavailable. Please feel free to browse our website for other available items.
Item Code SRCICO471698701
Brand Cisco Systems
Model 47-16987-01 Rev A0
Category Network Switches & Management
Condition Pre-Owned Grade C
Condition Description Please note, this unit is used and has minor scuffs and scratches, but is fully operational and functions as intended! Front plastic I/O is missing, no cables or any other accessories! Please see images below.
Description
Original Cisco 1800 Series 1841 Model Integrated Services Router. Cisco 1800 series integrated services routers are modular routers with LAN and WAN connections that can be configured by means of interchangeable interface cards and advanced integration modules (AIMs). The modular design of the routers provides flexibility, allowing you to configure or reconfigure your router according to your needs. The Cisco 1841 router is a data-only device for desktop use.
Cisco Model Number: 1841
Cisco Part Number: 47-16987-01 Rev A0 47-16987-03 Rev A0
Specifications:
| Description | Specification |
| Dimensions without rubber feet (H x W x D) | 1.73 x 13.5 x 10.8 in. (4.4 x 34.3 x 27.4 cm) With rubber feet, height is 1.87 in. (4.75 cm) |
| Weight (no modules installed) | 6.1 lb. (2.77 kg) |
| Input voltage, AC power supply Frequency | 100 to 240 VAC, autoranging 47 to 63 Hz |
| Power consumption | 20 W maximum for an unloaded unit. With two WICs and an AIM installed, power consumption will be less than 50 W. |
| Console and auxiliary ports | RJ-45 connectors |
| Operating humidity | 5 to 95%, noncondensing |
| Operating temperature | 32 to 104°F (0 to 40°C) |
| Non operating temperature shock | –13 to 158°F (–25 to 70°C) at 9° F (5° C)/minute minimum |
| Noise level | Normal operating temperature (< 78° F or 26° C): 34 dBa From (78° F or 26° C) through (104° F or 40° C): 37 dBa >104° F or 40° C: 42 dBa |
