Cisco Ethernet Switch WS-CE500-24TT
We apologize but this item is currently unavailable. Please feel free to browse our website for other available items.
Item Code NETSWWSCE50024T
Brand Cisco Systems
Model WS-CE500-24TT
Category Network Switches & Management
Condition Pre-Owned Grade B
Condition Description Please note, one of the rack ears is missing, but the item is fully operational and functions as intended! Unit only! No cables or any other accessories.
Description
Genuine Original Cisco Catalyst Express 500 Series 24-Port 10/100 Fast Ethernet Network Switch WS-CE500-24TT. Cisco Catalyst Express 500 switch deliver Cisco class networking tailored for businesses with up to 250 employees. Powered by Cisco Systems technology, this family of Layer 2-managed Fast Ethernet and Gigabit Ethernet switch offers nonblocking, wire-speed performance that provides a secure network foundation optimized for data, wireless, and voice. Built-in advanced security features help ensure that your devices and network are protected.
Part Number: WS-CE500-24TT
Specifications:
| Standards | IEEE 802.1d Spanning Tree Protocol IEEE 802.1p Class of service (CoS) classification IEEE 802.1q VLAN IEEE 802.1w Rapid Convergence Spanning Tree Protocol IEEE 802.1x Port Access Authentication IEEE 802.3ad Link Aggregation Control Protocol (LACP) IEEE 802.3x full duplex on 10BASE-T, 100BASE-TX, and 1000BASE-T ports IEEE 802.3 10BASE-T IEEE 802.3u 100BASE-T/TX IEEE 802.3ab 1000BASE-T IEEE 802.3z 1000BASE-X IGMP (v1, v2, and v3) snooping Per VLAN Spanning Tree Per VLAN Spanning Tree Plus Per VLAN Rapid Spanning Tree Plus Secure Sockets Layer (SSL) SNMPv3 (read-only) |
| Primary Ports | 24 10/100 RJ-45 Ports 2 10/100/1000BASE-T RJ-45 Ports |
| Primary Port Speed | 10/100Mbps + 1000Mbps |
| Security | SSL support: encrypts all HTTP traffic, allowing secure access to the browser-based management GUI in the switch Security policy slider High-bandwidth video traffic is optimized so that it does not affect other applications on the network. Internet Group Management Protocol (IGMP) (v1, v2, and v3) snooping: IGMP snooping constrains multicast traffic at Layer 2 by configuring Layer 2 LAN ports dynamically to forward multicast traffic only to those ports that want to receive it. |
| Cabling | 10/100BASE-TX ports: RJ-45 connectors; 2-pair Category 5 unshielded twisted pair (UTP) cabling 10/100/1000BASE-T ports: RJ-45 connectors; 4-pair Category 5 UTP cabling |
| Features | Power Consumption (maximum):30W or 102 BTUs per hour Input Voltage: AC input voltage/frequency: 100-240Vac, 1.3-0.8A, 50-60Hz |
