Dell Alienware M14X 340D7 DVD-RW Drive
We apologize but this item is currently unavailable. Please feel free to browse our website for other available items.
Item Code LTPDRGS40N340D7
Brand Dell Computers
Model 0340D7 CN-0340D7 GS40N
Category Laptop Optical Drives
Description
Dell Alienware M14X Series 340D7 SATA DVD-RW Super Multi DVD Writer Drive. Dell meets the current and future demands of high-performance, power embedded computing, making it ideal for communications, transaction terminal, interactive client, industrial automation applications, as well as for standard home use.
Dell Part Number: 340D7 0340D7 CN-0340D7
Hitachi-LG Model Number: GS40N
Compatible Models: Dell Alienware M14X Series
Specifications:
Summary | |
| Drive Type | Ultra Slim Internal DVD Writer (9.5mm, Slot Type) |
| Interface Type | SATA |
| Operating Systems | |
| Windows | Windows 8.1, Windows 8, Windows 7, Windows Vista, Windows XP, Windows Server 2008, Windows Server 2003 |
| Sustained Rate | |
| DVD-ROM | 11.08 MB/s (8x) max. |
| CD-ROM | 3.6 MB/s (24x) max. |
| Burst Transfer Rate | |
| SATA Gen.1 | 1.5Gbps (150MB/s |
| Buffer Size | |
| Buffer Size | 0.75MB Buffer Under-run prevention function embedded |
| Host Interface | |
| Internal (Drive) | SATA |
| Compliance | |
| RoHS | Yes |
| EMC/EMI | CE Marking, C-Tick (RCM) Mark, Korean EMC (KC), Taiwan EMC (BSMI), VCCI, FCC |
| Safety UL | UL 60950-1 First Edition |
| TÜV | EN 60950-1 / EN60825-1 |
| SEMKO | EN 60950-1 / EN60825-1 |
| Laser Safety | Class 1 laser product comply with DHHS rules 21 CFR Subchapter J Class 1 laser product to EN60825-1 / IEC 60825-1 |
| Transfer Rates-Write (MAX) | |
| CD-R | 10x CLV, 16x PCAV, 24x CAV |
| CD-RW | 4x, 10x CLV, 16x ZCLV, 24x ZCLV (High Speed: 10x CLV, Ultra Speed: 24x ZCLV, Ultra Speed plus: 24x ZCLV) |
| DVD+R | 2.4x CLV, 4x PCAV, 8x CAV |
| DVD+RW | 2.4x, 3.3x CLV, 4x ZCLV, 8x ZCLV (8x Speed disc: 3.3x CLV, 8x ZCLV) |
| DVD-R | 2x CLV, 4x PCAV, 8x CAV |
| DVD-RAM | 2x, 3x CLV, 5x, 12x PCAV |
| DVD-RW | 2x, 3x CLV, 4x, 6x ZCLV |
| DVD+R DL | 2x CLV, 4x, 6x ZCLV |
| System Requirements | |
| CPU | Intel Pentium4 2.4GHz or Higher |
| Recommended | Intel Pentium4 3.2GHz or Higher |
| RAM | 1 GB or Higher |
| Video Memory | 64 MB or Higher (128 MB recommended) |
| HDD | 20GB or more of available space |
| Transfer Rates - Read (MAX) | |
| DVD-RW | 8x CAV |
| DVD-Video(CSS Compliant Disc) | 4x CAV (SL/DL) |
| DVD-RAM | 6x CAV |
| DVD-R (SL/DL) | 8x CAV |
| DVD+RW | 8x CAV |
| DVD+R (SL/DL) | 8x CAV |
| CD-R/RW/ROM | 24x/24x/24x max. |
| CD-DA | 24x CAV |
| Other Features | |
| Other Features | Silent Play, Jamless Play |
| Access Time | |
| DVD-ROM | 160 ms typ. |
| DVD-RAM (Ver.2.2) | 260 ms typ. |
| CD-ROM | 140 ms typ. |
| Dimensions | |
| Dimensions (WxHxD) | 5.0" x 0.4" x 5.0" (128mm x 9.5mm x 127 mm) |
| Weight | |
| Weight | 0.3 lbs. (145g) |
