DELL DU-8A3S SLIM 8X DVD±RW W/OUT BEZEL

We apologize but this item is currently unavailable. Please feel free to browse our website for other available items.
Dell Du-8A3s Slim 8X Dvd±Rw W/Out Bezel. Model: Du8a3s Du-8A3s12c
  Enlarge
*Note this image is for descriptional purposes.
Actual product may vary.
Item Code LTPDRWDELDU8A3B
Brand Dell Computers
Model DU8A3S DU-8A3S12C
Category Laptop Optical Drives

Description

Dell DU-8A3S Slim 8X DVD±R/RW Optical Drive for Dell Latitude, Precision, Vostro and XPS Mobile Notebook Laptop Computers Systems. The Dell Internal DU-8A3S is a slim 8x DVD±R/RW SATA drive, with standard half inch design and horizontal and vertical mounting for most system configurations.

Brand: Dell
Manufacturer: Philips & LiteOn Digital Solutions
Model: DU-8A3S DU8A3S DU-8A3S12C
Type: Internal
Interface: SATA
Dell Part Numbers: 53T72 RWDMD 053T72 0RWDMD
Compatible Systems:
Latitude E4200
Latitude E6320
Latitude E6400
Latitude E6400 ATG
Latitude E6400 XFR
Latitude E6410
Latitude E6410 ATG
Latitude E6420
Latitude E6420 ATG
Latitude E6500
Latitude E6510
Latitude E6520
Latitude XT2
Latitude XT2_XFR
Dell Precision Mobile WorkStation M2400
Dell Precision Mobile WorkStation M4400
Dell Precision Mobile WorkStation M4500
Vostro Notebook 3300
Vostro Notebook 3350
XPS XPS 14 (L401X)

* This Optical Drive Does Not Include the Front Bezel / Face. In most instances the original bezel from the old drive can be removed and reused on a new drive.

Features:

  • 9.5mm internal slim DVD±R/RW Drive.
  • Tray type.
  • Serial ATA Interface (SATA) model.
  • Supports reading and writing to CD-R/RW, DVD-R/RW and DVD+R/RW.
  • Supports reading to CD-ROM and DVD-ROM.


    Specifications:

    CD Performance Read Max. 24X
      Digital Audio Extraction (DAE) Max. 24X
      Write CD-R Max. 24X
      Write CD-RW Max. 24X
    DVD Performance Read DVD Single Layer / Double Layer Max. 8X / 6X
      Read DVD+/-R Single Layer Max. 8X
      Read DVD-RAM Max. 5X
      Read DVD+/-R Double Layer Max. 6X
      Read DVD+/-RW Max. 6X
      Write DVD+/-R Max. 8X
      Write DVD-RAM Max. 5X
      Write DVD+/-R Double Layer Max. 4X
      Write DVD+RW Max. 8X
      Write DVD-RW Max. 6X
    Power Consumption Typical 5V / 200mA
    Acoustic noise Operating (Sound pressure level, typical) Under 45 db
    Power supply Voltage DC 5V
    Temperature Operating 0C (0F) 50C~500C (410F~1220F)
      Non-operating 0C (0F) -400C~650C (-400F~1490F)
    Relative Humidity Operating (No condensation) 20% to 80% RH
      Non-operating (No condensation, Power Off, without disc) 5% to 95% RH
    Altitude Operating m (ft) -200 ~ 3,048 m (-656 ~ 10,000 ft)
      MTBF: 150,000 POH at 15% duty cycle at 40C
    Dimensions and weight Width mm (in) 128 +/- 0.2 mm  (5.0 in +/- 0.008 in)
      Depth mm (in) 126.1 +/- 0.2 mm  (5.0 in +/- 0.008 in)
      Height mm (in) 9.5 + 0.5/- 0.2 mm (0.4 in + 0.02/- 0.008 in)
      Weight g 140 +/- 5 g
