DELL GCC-T10N SLIM DVD/CD-RW COMBO DRIVE
Actual product may vary.
Description
Dell GCC-T10N Slim CD-RW / DVD-ROM Combo Optical Drive for Dell Inspiron, Latitude and Precision Notebook Laptop Computers Systems. Dell Slim DVD/CD-RW Combo optical drive, with standard half inch design and horizontal and vertical mounting for most system configurations.
Brand: Dell
Manufacturer: Hitachi-LG
Model: GCC-T10N
Type: Internal
Interface: Enhanced-IDE (ATAPI)
Dell Part Numbers: FW002 0FW002
Compatible Systems:
Dimension Desktop 9200C
inspiron 1420
inspiron 1501
inspiron 1520
inspiron 1521
inspiron 1525
inspiron 1526
inspiron 1720
inspiron 1721
inspiron 640m
inspiron 9400/E1705
inspiron I6400/E1505
Latitude 131L
Latitude ATG D630
Latitude D420
Latitude D430
Latitude D520
Latitude D530
Latitude D531
Latitude D620
Latitude D630
Latitude D630c
Latitude D631
Latitude D820
Latitude D830
Latitude XFR D630
Latitude XT
OptiPlex 740
OptiPlex 745
OptiPlex 755
Precision M2300
Precision M4300
Precision M6300
Precision M65
Precision M90
Vostro Notebook 1000
Vostro Notebook 1400
Vostro Notebook 1500
Vostro Notebook 1700
Vostro Notebook Dell 500
XPS Desktop M1210
XPS Desktop M1710
XPS Desktop M17300
Specifications:
| System Interface | Host Interface | ATAPI compliant (X3T9.2/791D and SFF-8020 Rev 2.6) SFF-8090 Ver5.0, Rev MMC-4 (MMC Spec for CD-R/RW) |
| Data transfer speed | Max. 33.3 MB/s (UDMA Mode 2) | |
| Performance | ||
| CD | Read CD-ROM/ R/ RW | 24x CAV |
| Digital Audio Extraction (DAE) | 20x CAV | |
| Write CD-R | 4x CLV, 10x CLV, 10 - 16x PCAV, 24x CAV | |
| Write CD-RW | Multi Speed: 4x CLV High Speed: 10x CLV Ultra Speed: 10x CLV, 10 - 16x PCAV, 24x CAV | |
| DVD | ||
| Read DVD-ROM (Single Layer / Dual Layer) | 8x max. CAV | |
| Read DVD+R | 6x max. CAV | |
| Read DVD+R Double Layer | 6x max. CAV | |
| Read DVD+RW | 6x max. CAV | |
| Read DVD-R | 6x max. CAV | |
| Read DVD-R Double Layer | 6x max. CAV | |
| Read DVD-RW | 6x max. CAV | |
| Read DVD-Video (CSS title) | 4x max. CAV | |
| Power Consumption | Continuous Read | 700 mA typical (CD 24x max. CAV) 700 mA typical (DVD 8x max. CAV) |
| Continuous Write | 800 mA typical (CD-R 24x Write) | |
| Seek | 1000 mA typical 1500 mA max (24x max.CAV) | |
| Acoustic noise | Operating (Sound pressure level, typical) | Less than 41dBA at 0.25m away from bezel and 0.45m heights away. |
| Power supply | Voltage | +5V +/-5% ripple less than 100 mVp-p |
| Temperature | Operating 0C (0F) | 5 to 500C (410F to 1220F) |
| Non-operating 0C (0F) | -300C to 600C (-860F to 1400F) | |
| Relative Humidity | Operating (No condensation) | 15% to 85% |
| Non-operating (No condensation, Power Off, without disc) | 10% to 90% | |
| Altitude | Operating m (ft) | -200m ~ 3,048m |
| MTBF: | 80,000 hours (POH) | |
| Dimensions and weight | ||
| Width | 128 mm | |
| Depth | 129 mm | |
| Height | 12.7 mm | |
| Weight | About 180 g |
