Dell KW626 Optiplex GX745 MT LGA775 Motherboard. Dell meets the current and future demands of high performance, power embedded computing, making it ideal for communications, transaction terminal, interactive client, industrial automation applications as well as for standard home use.

Manufacturer: Dell
Part Number: KW626 0KW626 CN-0KW626

Specifications:

CHIPSET:

Intel Q965 Express

SUPPORTED PROCESSORS:

Intel Pentium 4
Pentium D
Celeron
Core
Socket 775

SUPPORTED MEMORY:

4 DIMM slots supporting up to 8 GB RAM

VIDEO:

Integrated onboard video

AUDIO:

Integrated Audio Sound Controller
ADI 1983 High Definition Audio

PERIPHERAL INTERFACES:

6 x 2.0 USB
1 x parallel printer port
1 x serial ports
4 x Serial ATA (SATA) Interface Ports
1 x 10/100/1000 Ethernet Port

EXPANSION CAPABILITY:

1 x PCI-E X16 slot, supports x16 x8 x4 and x1 modes/cards
1 x PCI-E x1 slot
2 x PCI 32Bit / 33MHz slots
1 x FDD connector

Compatible Models:

Dell Optiplex GX745 MT Desktop Series
