Dell Optiplex GX270 Motherboard J9057

We apologize but this item is currently unavailable. Please feel free to browse our website for other available items.
  Enlarge
*Note this image is for descriptional purposes.
Actual product may vary.
Item CodeMB4DELJ9057
BrandDell Computers
ModelJ9057 FG019 J2865
CategoryIntel P4 / Celeron 478-Pin Motherboards

Description

Dell Optiplex GX270 Motherboard Dell Part# C2057 X8677 X1105 D9076 H1291 H6405 DG286 0C2057 0X8677 0X1105 0D9076 0H1291 0H6405 0DG286 R6019 M2886 YF936 CG555 J9057 FG019 0FG019 ND515 R2472 0R2472 U1324 0U1324 0M2886 DG279 0DG279 H1105 0H1105 0YF936 0CG555 0D286 00D286 0R6019 X1078 U9268 N6016 R0786 0R0786 FC092 GD301 FG011 - Intel P4 i865 Chipset Desktop motherboard harnesses the advanced computing power of the latest Intel Pentium 4 processor supporting Hyper-Threading Technology.

Specifications:

Dell Compatible Part Number: C2057 X8677 X1105 D9076 H1291 H6405 DG286 0C2057 0X8677 0X1105 0D9076 0H1291 0H6405 0DG286 R6019 M2886 YF936 CG555 J9057 FG019 0FG019 ND515 R2472 0R2472 U1324 0U1324 0M2886 DG279 0DG279 H1105 0H1105 0YF936 0CG555 0D286 00D286 0R6019 X1078 U9268 N6016 R0786 0R0786 FC092 GD301 YF939 FG011

Please note the following this Dell GX270 Motherboard can also be used as a replacement for the following Dell Part Number: C2057 X8677 X1105 D9076 H1291 H6405 DG286 0C2057 0X8677 0X1105 0D9076 0H1291 0H6405 0DG286 R6019 M2886 YF936 CG555 J9057 FG019 0FG019 ND515 R2472 0R2472 U1324 0U1324 0M2886 DG279 0DG279 H1105 0H1105 0YF936 0CG555 0D286 00D286 0R6019 X1078 U9268 N6016 R0786 0R0786 FC092 GD301 FG011, however please note the difference is that the board we are offering has 2 Memory Dimm Slots and the following list has 4 Memory DIMM Slots, all other features are identical.

Form FactormicroATX (9.60 inches by 8.20 inches [233.68 millimeters by 208.28 millimeters])
Processor
  • Support for an Intel® Pentium® 4 processor in a mPGA478 socket with a 533/800 MHz system bus
  • Support for an Intel® Celeron® processor in a mPGA478 socket with a 400 MHz system bus from 2.4Ghz+
  • Hyper-Threading Technology Support
Memory
  • Two 184-pin DDR SDRAM DIMM sockets
  • Support for DDR 400, DDR 333, and DDR 266
ChipsetIntel® 865PE Chipset
I/O ControlLPC Bus I/O controller
AudioSound Audio subsystem for AC '97 processing
Video64MB Onboard Plus Universal 0.8/1.5 V AGP 3.0 connector supporting 1x, 4x, and 8x AGP cards or an AGP Digital Display (ADD) card
Peripheral Interfaces
  • Six USB 2.0 ports
  • One serial port
  • One parallel port
  • One 10/100 network port
  • One Serial ATA IDE interfaces
  • Two Parallel ATA IDE interfaces with UDMA 33, ATA-66/100 support
  • One Floppy FDD diskette drive interface
  • PS/2 keyboard and mouse ports
Expansion CapabilitiesOne PCI bus add-in card connectors (SMBus routed to PCI bus connector 2)
One AGP Slot supporting 1x, 4x, and 8x AGP cards
