YG554 740 745 755 | Dell Optiplex Slim Dvd±Rw Optical Drive

Dell Slim DVD±R/RW Optical Drive with a mounting bracket (sled) and IDE to SATA Interposer YG554 for use in Dell Optiplex 740, 745 and 755 Desktop Computer System. Dell Slim DVD±R/RW optical drive, with standard half inch design and horizontal and vertical mounting for most system configurations.

Brand: Dell
Dell Part Numbers: YG554 0YG554 PR424 0PR424 UN166 0UN166 XJ021 0XJ021 KN132 0KN132 XK909 0XK909 XT236 0XT236 WM135 0WM135
Models: DR-K17YB DS-8W1P TS-L632 GSA-T11N GSA-T21N SDVD8820 AD-5560A AD-5540A
Type: Internal
Interface: IDE with IDE to SATA adapter
Compatible Systems:
OptiPlex 740
OptiPlex 745
OptiPlex 755

Features:

12.7mm internal slim DVD±R/RW Drive.

Tray type.

IDE / E-IDE Interface

Supports reading and writing to CD-R/RW, DVD-R/RW and DVD+R/RW.

Supports reading to CD-ROM and DVD-ROM.

IDE to SATA Interposer Board (YG554)

Specifications:

System Interface	Data transfer speed	Max. 33.3 MB/s (UDMA Mode 2)
Performance
CD
	Read	Max. 24X
	Digital Audio Extraction (DAE)	Max. 12X
	Write CD-R	Max. 24X
	Write CD-RW	Max. 24X
DVD
	Read (Single Layer / Dual or Double Layer)	Max. 8X/6X
	Write DVD+/-R	Max. 8X
	Write DVD+R/-R Double Layer	Max. 4X/4X
	Write DVD+RW	Max. 8X
	Write DVD-RW	Max. 6X
	Write DVD-RAM	Max. 5X
Power Consumption	Typical	DC+ 5V / 1.3A
Acoustic noise	Operating (Sound pressure level, typical)	Under 45 dBA
Power supply	Voltage	DC +5 V±5%
Temperature	Operating°C (F)	5°C ~ 50°C (41°F ~ 122°F)
	Non-operating C (F)	-40°C ~ 65°C (-40°F ~ 149°F)
Relative Humidity	Operating (No condensation)	10% ~ 90%
	Non-operating (No condensation, Power Off, without disc)	5% ~ 95%
Altitude	Operating m (ft)	3,048m (10,000 ft)
	MTBF:	60 000 hours
Dimensions and weight
	Width mm (in)	128 +/- 0.2 mm (5.04 +/- 0.01 in)
	Depth mm (in)	127 mm (5 in)
	Height mm (in)	12.7 +/- 0.2 mm (0.5 +/- 0.01 in)
	Weight (g)	165g
