Dell PowerEdge 1750 J3014 Motherboard

Dell PowerEdge 1750 Server Motherboard. Dell Part Number: J3014 8T570 K2306 P1348 J2573. The Intel board harnesses the advanced computing power of the latest Intel Xeon processor supporting Hyper-Threading Technology.

Manufacturer: Intel
Dell Compatible Part: J3014 0J3014 CN-0J3014 8T570 08T570 CN-08T570 K2306 0K2306 CN-0K2306 P1348 0P1348 CN-0P1348 C1047 0C1047 0CN-C1047 J2573 0J2573 CN-0J2573
Application: Dell PowerEdge 1750

Specifications:

Socket: 604 (Dual processor)
Processor Type: Dual Intel Xeon (up to 3.2GHz) supporting Hyper-Threading Technology
Cache: 512KB Level 2 ECC cache (full speed), 1MB and 2MB L3 (selected processors)
Video: On-board
SCSI: 68-pin U320 SCSI connector
Serial: 9-pin connector
USB: 4-pin connectors
NIC: two RJ45 connectors for integrated 10/100/1000 NICs
RAC: one RJ45 connector for optional RAC (100 Mbit Ethernet controller)
Video: 15-pin connector
PS/2-style keyboard: 6-pin mini-DIN connector
PS/2-compatible mouse: 6-pin mini-DIN connector
Video (front): 15-pin connector
USB (front): 4-pin connector
Memory Type: 256MB/8GB of 266MHz DDR SDRAM
Memory Connectors: four 72-bit wide 184-pin DIMM sockets
Capacities: 128-MB, 256-MB, 512-MB, 1-GB, or 2-GB registered DDR SDRAM DIMMs, rated for 266-MHz operation
Minimum Memory: 256 MB
Maximum Memory: 8 GB
Expansion Bus Type: PCI, PCI-X
Expansion:
two 3.3-V, 64-bit, 133-MHz PCI-X slots or
one 3.3-V, 64-bit, 133-MHz PCI-X slot and
one 5-V 64-bit, 33-MHz PCI slot
