DELL SCB5265 SLIM DVD/CD-RW COMBO DRIVE
We apologize but this item is currently unavailable. Please feel free to browse our website for other available items.
Enlarge
*Note this image is for descriptional purposes.
Actual product may vary.
Actual product may vary.
Item Code LTPDCOMBSCB5265
Brand Dell Computers
Model SCB5265 CC753 0CC753
Category Laptop Optical Drives
Description
Dell SCB5265 Slim CD-RW / DVD-ROM Combo Optical IDE Drive for Dell Laptop Notebooks and Computers Systems. This CD-RW / DVD-ROM Combo drive reads CD and DVD media and writes to CD media.
Brand: Dell
Manufacturer: Philips
Model: SCB5265
Type: Internal
Interface: Enhanced-IDE (ATAPI)
Dell Part Numbers: CC753 0CC753
Compatible Systems:
Dell Inspiron: 630m, 640m, 1200, 1300, 1501, 2200, 6000, 6400, 9200, 9300, 9400, B120, B130, E1405, E1505, and E1705
Dell Latitude: 120L and 131L
Dell Precision WorkStation: M90
Dell XPS: M140 and M1710
Dimension: Desktop 5100C 5150C
OptiPlex: 740 745
Specifications:
| General | |
| Manufacturer | Philips |
| Model Number | SCB5265 |
| Interface | IDE/ATAPI |
| Data Buffer Memory | 2 MB |
| Read Function | |
| Applicable Format | DVD-ROM/Video 5, 9, 10, 18 |
| DVD-R 3.95/4.7G | |
| DVD+R 4.7G | |
| DVD-RW: 4.7G | |
| CD-ROM Mode-1 | |
| CD-ROM XA | |
| CD-Audio | |
| Mixed Mode CD-ROM (Audio and Data Combined) | |
| Photo-CD (Single and Multi-session) | |
| CD-I, Video CD | |
| CD-Plus / CD-Extra, CD-Text | |
| Super Video CD | |
| CD-R disc (Conforming to Orange Book Part2) | |
| CD-RW disc (Conforming to Orange Book Part3) | |
| Write Function | |
| Applicable Format | CD-ROM Mode-1 |
| CD-ROM XA | |
| CD-Audio | |
| Mixed Mode (Audio and Data Combined) | |
| Video CD | |
| CD-Extra, CD-Text | |
| Write Method | |
| Method | Disc at once (DAO) |
| Session at once (SAO) | |
| Multi-session | |
| Track at once (TAO) | |
| Variable packet writing | |
| Fixed packet writing | |
| Extended Specifications | |
| Burst Transfer Rate | 33.3 Mbytes/s max. (Ultra DMA Mode 2) |
| 16.6 Mbytes/s max. (DMA MW Mode 2) | |
| 16.6 Mbytes/s max. (PIO Mode 4) | |
| Average access time | DVD-ROM <150ms |
| CD-ROM | |
| Mounting direction | Horizontal/Vertical |
| Loading system | Drawer Type Manual Load |
| Power | DC 5 +/- 5%(100 mVp-p Max, 1 KHz ~ 10 MHz) |
| Weight | Less than 190g |
| Dimensions | 128 x 129 x 12.7 mm (Width, depth, height) |
| Data Error Rate | DVD 10E-15 (hard read error) |
| CD Mode-1 ECC on 10E-12 (hard read error) | |
| CD Mode-2 ECC off 10E-9 (soft read error) | |
| MTBF | 60,000 POH (20% duty cycle, seek and read) |
| MTTR | Within 30 minutes |
| Audio Output Level | 0.725 Vrms +/- 10% |
