Dell W-650 Wireless Access Point 2T7CK

Dell PowerConnect W-650 Aruba 650-US Mobility Wireless Access Controller 2T7CK 02T7CK US-02T7CK. The Dell PowerConnect W-650 and W-651 Controllers are compact and cost-effective wireless network control solutions. The W-650 includes an 8-port Ethernet switch and IP router while the W-651 has an integrated single-radio, dual-band 802.11a/b/g/n wireless access point that delivers wire-like performance at up to 300Mbps data rates.

- Secure your network with a wireless firewall, intrusion protection, end-to-end encryption and role-based access control.
- Simplify network setup and administration with RF planning, location tracking and live RF heat maps.
- Optimize network functionality with print server and network attached storage capabilities, VPN client termination and site-to-site VPN.

Dell Part Number: 2T7CK 02T7CK US-02T7CK
Dell Model Number: PowerConnect W-650
Aruba Model Number: 650-US

Included:
Unit
VGA/Network Adapter
Network Cable
Rack Mount Brackets







Specifications:


Performance and Capability with W-ArubaOS Controller Software

LAN-connected Access Points (maximum): 16
Remote Access Points (maximum): 64
Users (max): 512
MAC addresses: 2,048
VLAN IP interfaces: 128
Number of IPv4 unicast routes: 2,048
Active firewall sessions: 16,384
System BSSIDs: 128
Concurrent IPsec tunnels (max): 512
Firewall throughput: 2 Gbps
Encrypted throughput (3DES): 1.6 Gbps
Encrypted throughput (AES-CCM): 800 Mbps

Interfaces

Console (RS-232) RJ-45: 1
Gigabit Ethernet (10/100/1000Base-T): 2
Gigabit Ethernet (10/100/1000Base-T) with PoE+: 4
Gigabit Ethernet pluggable (1000Base-X SFP): 2
ExpressCard: 1
USB 2.0: 4

Operating Specifications and Dimensions

Operating temperature range: 0° to 40° C (32°F to +104°F)
Storage temperature range: 0° to 50°C (32°F to 122°F)
Humidity, non-condensing: 5 to 95%
Height: 38 mm
Width: 346 mm
Depth: 226 mm
Weight: 4.9 lbs/2.2 kgs

Power Specifications

AC input voltage: 100-240 V, Universal Input
AC input frequency: 50-60 Hz
Maximum power consumption: 126 Watts
Power over Ethernet total capacity: 78 Watts
Power over Ethernet total capacity: 19.5 Watts

USB Device Support

Maximum concurrent printers: 2
Maximum concurrent HSDPA/GPRS/EDGE/EVDO Modems: 2
Maximum concurrent storage media (Hard disk/Flash): 4
Maximum concurrent devices (all types): 4







Integrated wireless access controller

PowerConnect W-600 series controllers are integral components of Dell’s enterprise network architecture, which uses central controllers in the data center to manage complex, processing-intensive management and security functions. W-600 series controllers also virtualize and implement edge services, moving user traffic to data-center controllers through secure IP tunnels over a public or private transport network.

W-600 series controllers can provide local wireless services when used with any PowerConnect W-Series access point, or they can operate as wired-only devices. The controllers also include print server and network-attached storage capabilities to enable local network printing and mass storage.
