Dell XPS 1640 SATA DVD-RW Drive 1D51J
We apologize but this item is currently unavailable. Please feel free to browse our website for other available items.
Enlarge
*Note this image is for descriptional purposes.
Actual product may vary.
Actual product may vary.
Item CodeLTPDVDRW1D51JDE
BrandDell Computers
Model1D51J CN-01D51J TS-T633
CategoryLaptop Optical Drives
Description
Dell 1D51J Slim 8x DVD±RW Slot loading 12.7mm height internal SATA Drive for Dell Laptop Notebook and some Slim Desktop Computers Systems. This drive reads CD and DVD media and writes to CD and DVD media.
Manufacturer: Dell
Model: TS-T633 TS-T633C/DEFH
Dell Part Numbers: 1D51J 01D51J CN-01D51J
Compatible Systems:
Studio XPS 1640
Studio XPS 1645
Studio XPS 1647
* This Optical Drive Does Not Include the Front Bezel / Face. In most instances the original bezel from the old drive can be removed and reused on a new drive.
Features:- 12.7mm internal slim DVD±R/RW Drive
- Slot loading type
- Serial ATA Interface (SATA) model
- Supports reading and writing to CD-R/RW, DVD-R/RW and DVD+R/RW
- Supports reading to CD-ROM and DVD-ROM
Specifications:
| System Interface | Data transfer speed | Max. 133 MB/s |
| Performance | ||
| CD | Read | Max 24X |
| Digital Audio Extraction (DAE) | Max 24X | |
| Write CD-R | Max 24X | |
| Write CD-RW | Max 24X | |
| DVD | Read (Single Layer / Dual or Double Layer) | Max 8X / 6X |
| Write DVD+/-R | Max 8X | |
| Write DVD+R Double Layer | Max 6X | |
| Write DVD-R Double Layer | Max 6X | |
| Write DVD-RAM | Max 5X | |
| Write DVD+RW | Max 8X | |
| Write DVD-RW | Max 6X | |
| Power Consumption | Typical | DC+ 5V / 1.3A |
| Acoustic noise | Operating (Sound pressure level, typical) | Under 45 dBA |
| Power supply | Voltage | 5V |
| Temperature | Operating C (F) | 5 ~ 50 °C (41 ~ 122 °F) |
| Non-operating C (F) | -40 ~ 65 °C (-40 ~ 149 °F) | |
| Relative Humidity | Operating (No condensation) | 10 ~ 90 (%RH) |
| Non-operating (No condensation, Power Off, without disc) | 5 ~ 95 (%RH) | |
| Altitude | Operating m (ft) | 3,048m (10,000 ft) |
| MTBF: | 60,000 hours | |
| Dimensions and weight | Width mm (in) | 128 +/- 0.2 mm (5.04 +/- 0.01 in) |
| Depth mm (in) | 127 mm (5 in) | |
| Height mm (in) | 12.7 +/- 0.2 mm (0.5 +/- 0.01 in) | |
| Weight g | 165g | |
