ECS H81H3-MV V1.0 Micro ATX Motherboard

We apologize but this item is currently unavailable. Please feel free to browse our website for other available items.
Ecs H81h3-Mv V1.0 Micro Atx Motherboard
  Enlarge
Ecs H81h3-Mv V1.0 Micro Atx Motherboard
Ecs H81h3-Mv V1.0 Micro Atx Motherboard
Ecs H81h3-Mv V1.0 Micro Atx Motherboard
*Note this image is for descriptional purposes.
Actual product may vary.
Item Code MBECSH81H3MVV10
Brand Ecs - Elitegroup
Model H81H3-MV V1.0
Category Intel Lga1150 Motherboard

Description

ECS H81H3-MV V1.0 Intel H81 Socket LGA1150 DDR3 Micro ATX Motherboard.





Features:

3 Phase Power Design

ECS Durathon Technology ensure the stability, reliability and performance of system.

ESD Protection prevents computers from electrostatic discharge damage to enhance its durability and lifespan

Supports ECS EZ BIOS for tweaking BIOS in graphical user interface within a multi language environment

ECS MIB III - A friendly interface for overclocking

2 COM designed for various IPC applications

Integrated Printer (LPT) port / header to expand functionality

Microsoft Windows 8 Certified

Intel® 22nm 4th generation Multi-Core CPU support

Intel ® VRD 12.5 Ready

Supports DirectX® 11.1 to enhance graphical performance

Supports HDMI 1.4a Technology ( resolution up to 1920X1200 ) and HDCP function

ECS Intelligent EZ Utility : eBLU, eDLU, eSF

Free Bundle: CyberLink Media Suite




Specifications:


CPU

º Supports New 4th & 4th gen Intel® Core™ family, Pentium, Celeron series processors in LGA1150 socket
º DMI 5.0GT/s
º 4 Phase Thermal Design Power
º 100% Solid capacitor design
º Intel® K Series Unlock CPU Support

CHIPSET

º Intel® H81 Express Chipset

GRAPHICS

º Supports DirectX® 11 .1

MEMORY

º Dual-channel DDR3 Memory architecture
º 2 X 240-pin DDR3 DIMM socket
º Support up to 16 GB*

EXPANSION SLOT

º 1 X PCI Express X16 Gen 2.0 slot(s)
º 1 X PCI Express X 1 Gen 2.0 slot(s)

Storage

º Support by H81 Express Chipset
    • 2 X Serial ATAIII 6Gb/s
    • 2 X Serial ATAII 3Gb/s

Audio

º 6-Channel HD audio CODEC
º Realtek ALC662
‧Realtek ALC662 6-channel High Definition audio CODEC
‧Meets performance requirements for Microsoft WLP 3.08 Vista premium and mobile PCs
‧Six channel DAC supports 16/20/24-bit PCM format for 5.1 channel audio solution
‧Emulation of 26 sound environments to enhance gaming experience
‧Voice Cancellation and Key Shifting in Karaoke mode
‧Compatible with Direct Sound 3D™, A3D™, I3DL2

LAN

º Realtek 8111G Gigabit Fast Ethernet Controller

USB

º 2 X USB3.0 port(s) up to 5Gb/s (either rear I/O or front header)
      Back Panel 2 port(s)
    • 6 X USB2.0 port(s) Up to 480 Mb/s
      Back Panel 2 port(s)
      Onboard 4 port(s)

REAR PANEL I/O

º 1 X Audio port (Line Out/Line In/Mic In)
º 1 X RJ-45 port
º 1 X HDMI port(s)
º 1 X DVI-D port(s)
º 1 X D-Sub (VGA) port(s)
º 2 X USB3.0 port(s)
º 4 X USB2.0 port(s)

CONNECTORS & HEADERS

º 1 X 24-pin ATX Power Supply connector
º 1 X 4-pin 12V Power connector
º 1 X 4-pin CPU_FAN connector with smart fan
º 1 X 3-pin SYS_FAN connector
º 1 X Front Panel switch/LED header
º 1 X Front panel audio header
º 2 X USB 2.0 header
    • Support additional 4 USB ports
º 1 X S/PDIF out header
º 1 X CLR_CMOS header
º 1 X Serial port header (COM)

SYSTEM BIOS

º AMI BIOS with 64 MB SPI Flash ROM
º Supports M.I.B III Utility
º F7 hot key for boot up devices option
º Dual Display
º Support GUI UEFI BIOS
º Multi-Language BIOS
º Audio, LAN, can be disabled in BIOS
º Supports PgUp clear CMOS Hotkey

FORM FACTOR

º mATX Form Factor
º 225X170mm

OS Support

º Windows 7 32-bit
º Windows 7 64-bit
º Windows 8 32-bit
º Windows 8 64-bit
º Windows 8.1 32-bit
º Windows 8.1 64-bit

Certifications

º CE/FCC Certification
º ErP/EuP Certification
º WHQL Certification

Bundled Software

º ECS Intelligent EZ Utility : eBLU, eDLU, eSF
º Free Bundle: CyberLink Media Suite




CPU Socket List:

* means validated by ECS at time of writing. Changes to component or CPU may produce a different outcome. The result shown is for reference only and is subject to change w/o notification.



Socket

Family

Processor

Wattage

Frequency

Cache

Stepping

Since BIOS

LGA1150

Intel Xeon

E3-1231 v3

80W

3.40GHz

8MB

C0

03/10/2014

LGA1150

Intel Core™ i7

4765T

35W

2.00GHz

8MB

C0

03/10/2014

LGA1150

Intel Core™ i7

4770

84W

3.40GHz

8MB

C0

03/10/2014

LGA1150

Intel Core™ i7

4770K

84W

3.50GHz

8MB

C0

03/10/2014

LGA1150

Intel Core™ i7

4770S

65W

3.10GHz

8MB

C0

03/10/2014

LGA1150

Intel Core™ i7

4770T

45W

2.50GHz

8MB

C0

03/10/2014

LGA1150

Intel Core™ i7

4771

84W

3.50GHz

8MB

C0

03/10/2014

LGA1150

Intel Core™ i7

4785T

35W

2.20GHz

8MB

C0

08/11/2014

LGA1150

Intel Core™ i7

4790

84W

3.60GHz

8MB

C0

08/11/2014

LGA1150

Intel Core™ i7

4790S

65W

3.20GHz

8MB

C0

08/11/2014

LGA1150

Intel Core™ i7

4790T

45W

2.70GHz

8MB

C0

08/11/2014

LGA1150

Intel Core™ i5

4430

84W

3.00GHz

6MB

C0

03/10/2014

LGA1150

Intel Core™ i5

4430S

65W

2.70GHz

6MB

C0

03/10/2014

LGA1150

Intel Core™ i5

4440

84W

3.10GHz

6MB

C0

03/10/2014

LGA1150

Intel Core™ i5

4440S

65W

2.80GHz

6MB

C0

03/10/2014

LGA1150

Intel Core™ i5

4460

84W

3.20GHz

6MB

C0

08/11/2014

LGA1150

Intel Core™ i5

4460S

65W

2.90GHz

6MB

C0

08/11/2014

LGA1150

Intel Core™ i5

4460T

35W

1.90GHz

6MB

C0

08/11/2014

LGA1150

Intel Core™ i5

4570

84W

3.20GHz

6MB

C0

03/10/2014

LGA1150

Intel Core™ i5

4570S

65W

2.90GHz

6MB

C0

03/10/2014

LGA1150

Intel Core™ i5

4570T

35W

2.90GHz

4MB

C0

03/10/2014

LGA1150

Intel Core™ i5

4590

84W

3.30GHz

6MB

C0

08/11/2014

LGA1150

Intel Core™ i5

4590S

65W

3.00GHz

6MB

C0

08/11/2014

LGA1150

Intel Core™ i5

4590T

35W

2.00GHz

6MB

C0

08/11/2014

LGA1150

Intel Core™ i5

4670

84W

3.40GHz

6MB

C0

03/10/2014

LGA1150

Intel Core™ i5

4670K

84W

3.40GHz

6MB

C0

03/10/2014

LGA1150

Intel Core™ i5

4670S

65W

3.10GHz

6MB

C0

03/10/2014

LGA1150

Intel Core™ i5

4670T

45W

2.30GHz

6MB

C0

03/10/2014

LGA1150

Intel Core™ i5

4690

84W

3.50GHz

6MB

C0

08/11/2014

LGA1150

Intel Core™ i5

4690S

65W

3.20GHz

6MB

C0

08/11/2014

LGA1150

Intel Core™ i5

4690T

45W

2.50GHz

6MB

C0

08/11/2014

LGA1150

Intel Core™ i3

4130

54W

3.40GHz

3MB

C0

03/10/2014

LGA1150

Intel Core™ i3

4130T

35W

2.90GHz

3MB

C0

03/10/2014

LGA1150

Intel Core™ i3

4150

54W

3.50GHz

3MB

C0

08/11/2014

LGA1150

Intel Core™ i3

4150T

35W

3.00GHz

3MB

C0

08/11/2014

LGA1150

Intel Core™ i3

4160

54W

3.60GHz

3MB

C0

08/11/2014

LGA1150

Intel Core™ i3

4160T

35W

3.10GHz

3MB

C0

08/11/2014

LGA1150

Intel Core™ i3

4330

54W

3.50GHz

4MB

C0

03/10/2014

LGA1150

Intel Core™ i3

4330T

35W

3.00GHz

4MB

C0

03/10/2014

LGA1150

Intel Core™ i3

4340

54W

3.60GHz

4MB

C0

03/10/2014

LGA1150

Intel Core™ i3

4350

54W

3.60GHz

4MB

C0

08/11/2014

LGA1150

Intel Core™ i3

4350T

35W

3.10GHz

4MB

C0

08/11/2014

LGA1150

Intel Core™ i3

4360

54W

3.70GHz

4MB

C0

08/11/2014

LGA1150

Intel Core™ i3

4360T

35W

3.20GHz

4MB

C0

08/11/2014

LGA1150

Intel Core™ i3

4370

54W

3.80GHz

4MB

C0

08/11/2014

LGA1150

Intel Pentium

G3220

53W

3.00GHz

3MB

C0

03/10/2014

LGA1150

Intel Pentium

G3220T

35W

2.60GHz

3MB

C0

03/10/2014

LGA1150

Intel Pentium

G3240

53W

3.10GHz

3MB

C0

08/11/2014

LGA1150

Intel Pentium

G3240T

35W

2.70GHz

3MB

C0

08/11/2014

LGA1150

Intel Pentium

G3250

53W

3.20GHz

3MB

C0

08/11/2014

LGA1150

Intel Pentium

G3250T

35W

2.80GHz

3MB

C0

08/11/2014

LGA1150

Intel Pentium

G3420

53W

3.20GHz

3MB

C0

03/10/2014

LGA1150

Intel Pentium

G3420T

35W

2.70GHz

3MB

C0

03/10/2014

LGA1150

Intel Pentium

G3430

53W

3.30GHz

3MB

C0

03/10/2014

LGA1150

Intel Pentium

G3440

53W

3.30GHz

3MB

C0

08/11/2014

LGA1150

Intel Pentium

G3440T

35W

2.80GHz

3MB

C0

08/11/2014

LGA1150

Intel Pentium

G3450

53W

3.40GHz

3MB

C0

08/11/2014

LGA1150

Intel Pentium

G3450T

35W

2.90GHz

3MB

C0

08/11/2014

LGA1150

Intel Pentium

G3460

53W

3.50GHz

3MB

C0

08/11/2014

LGA1150

Intel Celeron

G1820

65W

2.70GHz

2MB

C0

03/10/2014

LGA1150

Intel Celeron

G1820T

35W

2.40GHz

2MB

C0

03/10/2014

LGA1150

Intel Celeron

G1830

65W

2.80GHz

2MB

C0

03/10/2014

LGA1150

Intel Celeron

G1840

53W

2.80GHz

2MB

C0

08/11/2014

LGA1150

Intel Celeron

G1840T

35W

2.50GHz

2MB

C0

08/11/2014

LGA1150

Intel Celeron

G1850

53W

2.90GHz

2MB

C0

08/11/2014
