ECS NFORCE9M-A AM2+ GEFORCE 8 DDR2 MB

We apologize but this item is currently unavailable. Please feel free to browse our website for other available items.
Ecs Nforce9m-A Am2+ Geforce 8 Ddr2 Mb. Model: Nforce9m-A 89-206-V46110
  Enlarge
*Note this image is for descriptional purposes.
Actual product may vary.
Item Code MB64ECSNFORCE9M
Brand Ecs - Elitegroup
Model NFORCE9M-A 89-206-V46110
Category Amd Socket Am2+ Am3 Motherboards

Description

ECS NFORCE9M-A V1.0 Single-Chip and Socket AM2+ for AMD Phenom™ Processor motherboard support the new socket AM2+ for AMD Phenom™ processor, and features the NVIDIA GeForce 8100 integrated chipset and equipped with new technologies PCI-E Gen. 2, HT3.0 bus for faster I/O. It support Dual-channel DDR2 memory up to DDR2 1066*. NFORCE9M-A motherboard delievers the outstanding performance for AMD platform.

Specifications:

CPU:
AMD Phenom™II / Phenom™ processor (Socket AM2+)
AMD Athlon™ 64 X2 Dual Core/ Athlon™ 64 / Sempron processor
High-performance HyperTransport 3.0 CPU Interface
Support transfer rate up to 5200 mega-transfers per second
Note: This board supports CPU up to 95W TDP only; you can refer to AMD website to check your CPU.
AM3 Ready

CHIPSET:
NVIDIA GeForce 8 Series

GRAPHICS:
Support NVIDIA GeForce® Boost for improved gaming performance with NVIDIA GPU

MEMORY:
Dual-channel DDR2 1066 memory architecture
4 x 240-pin DDR2 DIMM socket support up to 32GB
Support DDR2 1066/800/667/533/400 DDR2 SDRAM

EXPANSION SLOTS:
1 x PCI Express x16 Gen2.0 slot (Support Hybrid SLI)
2 x PCI Express X 1 Gen1.1 slot
3 x PCI slots

STORAGE:
Support by NVIDIA GeForce8100
2 x Ultra DMA133/100/66 devices
5 x Serial ATA 3.0Gb/s devices
RAID0, RAID1, RAID0+1, RAID5 configuration

AUDIO:
IDT 92HD202 6-channel audio ( CO-lay 92HD206)
Compliant with 6ch HD audio specification

LAN:
Realtek RTL8111 Gigabit Fast Ethernet Controller (Co-lay RTL8101E)

REAR PANEL I/O:
1 x PS/2 keyboard & PS/2 mouse connectors
6 x USB 2.0 ports
1 x Ethernet Port
1 x Audio port (Line-in, Line-out, Mic-in)

INTERNAL I/O CONNECTORS & HEADERS:
1 x 24-pin ATX Power Supply connector
1 x 4-pin 12V Connector
1 x 4pin CPU_FAN connectors
1 x 3-pin SYS_FAN connector
1 x IDE connector
1 x FDD connector
5 x Serial ATA connectors
(SATA4 & 5 only can work under AHCI or RAID mode due to NVIDIA chipset limitation)
1 x Speaker header
1 x Front panel audio header
1 x Front panel switch/LED header
1 x SPDIF out header
1 x CLR COMS
1 x IR header
1x CD in header
1 x COM1 header
3 x USB headers

SYSTEM BIOS:
AMI BIOS with 8Mb SPI Flash ROM
Supports Plug and Play, STR/STD, Hardware monitor, Multi Boot, DMI
Supports ACPI 3.0 revision

FORM FACTOR:
ATX Size, 305mm*220mm

Product Type: Recertified




CPU SUPPORT LIST:
SocketFamilyProcessorFrequencyCache
Socket AM2+AMD Athlon 64 X2 Dual-Core7850 (B3) (95W)2800Mhz512KB X 2
Socket AM2+AMD Athlon 64 X2 Dual-Core7750 (B3)(95W)2500 MHz512KB X 2
Socket AM2+AMD Athlon 64 X2 Dual-Core7750 (B3)(95W)2700 MHz512KB X 2
Socket AM2+AMD Athlon 64 X2 Dual-Core7550 (B3) (95W)2500Mhz512KB X 2
Socket AM2+AMD Athlon 64 X2 Dual-Core7450 (B3)(95W)2400 MHz512KB X 2
Socket AM2+AMD Athlon 64 X2 Dual-Core6500 (B3) (95W)2300 MHz1MBX2
Socket AM2AMD Athlon 64 X2 Dual-Core6000+ (F3)(89W)3000 MHz1MBx2
Socket AM2AMD Athlon 64 X2 Dual-Core6000+ (F2)(89W)3100 MHz1MBx2
Socket AM2AMD Athlon 64 X2 Dual-Core5800+ (G2)(89W)3000MHz512KBx2
Socket AM2AMD Athlon 64 X2 Dual-Core5600+ (G2)(65W)2900MHz512KBx2
Socket AM2AMD Athlon 64 X2 Dual-Core5400+ (G2)(65W)2800MHz512KBx2
Socket AM2AMD Athlon 64 X2 Dual-Core5400+ (G1)(65W)2800MHz512KBx2
Socket AM2AMD Athlon 64 X2 Dual-Core5400+ (F3)(89W)2800MHz512KBx2
Socket AM2AMD Athlon 64 X2 Dual-Core5200+ (G1)(65W)2700 MHz512KBx2
Socket AM2AMD Athlon 64 X2 Dual-Core5200+ (F3)(89W)2600 MHz1MBx2
Socket AM2AMD Athlon 64 X2 Dual-Core5200+ (F3)(65W)2600 MHz1MBx2
Socket AM2AMD Athlon 64 X2 Dual-Core5200+ (F2)(89W)2600 MHz1MBx2
Socket AM2AMD Athlon 64 X2 Dual-Core5050e (G2) (45W)2500 MHz512KB X 2
Socket AM2AMD Athlon 64 X2 Dual-Core5000+ (G2)(65W)2600 MHz1MB x 2
Socket AM2AMD Athlon 64 X2 Dual-Core5000+ (G2) (65W)2400MHz512KBx2
Socket AM2AMD Athlon 64 X2 Dual-Core5000+ (G1)(65W)2600 MHz512KBx2
Socket AM2AMD Athlon 64 X2 Dual-Core5000+ (F3)(89W)2600 MHz512KBx2
Socket AM2AMD Athlon 64 X2 Dual-Core5000+ (F3)(65W)2600 MHz512KBx2
Socket AM2AMD Athlon 64 X2 Dual-Core5000+ (F2)(89W)2600 MHz512KBx2
Socket AM2+AMD Athlon 64 X2 Dual-Core5000+ (C2) (65W)2200 MHz512KB X 2
Socket AM2AMD Athlon 64 X2 Dual-Core4850e (G2)(45W)2500MHz512KBx2
Socket AM2AMD Athlon 64 X2 Dual-Core4800+ (G1)(65W)2500MHz512KBx2
Socket AM2AMD Athlon 64 X2 Dual-Core4800+ (F2)(89W)2400 MHz1MBx2
Socket AM2AMD Athlon 64 X2 Dual-Core4800+ (F2)(65W)2400MHz1MBx2
Socket AM2AMD Athlon 64 X2 Dual-Core4600+ (F3)(65W)2400 MHz512KBx2
Socket AM2AMD Athlon 64 X2 Dual-Core4600+ (F2)(89W)2400MHz512KBx2
Socket AM2AMD Athlon 64 X2 Dual-Core4600+ (F2)(65W)2400 MHz512KBx2
Socket AM2AMD Athlon 64 X2 Dual-Core4450e (G2)(45W)2300MHz512KBx2
Socket AM2AMD Athlon 64 X2 Dual-Core4400+ (G2)(65W)2300 MHz512KB x 2
Socket AM2AMD Athlon 64 X2 Dual-Core4400+ (G1)(65W)2300MHz512KBx2
Socket AM2AMD Athlon 64 X2 Dual-Core4400+ (F2)(89W)2200MHz1MBx2
Socket AM2AMD Athlon 64 X2 Dual-Core4400+ (F2)(65W)2200 MHz1MBx2
Socket AM2AMD Athlon 64 X2 Dual-Core4200+ (F3)(35W)2200 MHz512KBx2
Socket AM2AMD Athlon 64 X2 Dual-Core4200+ (F2)(89W)2200 MHz512KBx2
Socket AM2AMD Athlon 64 X2 Dual-Core4200+ (F2)(65W)2200MHz512KBx2
Socket AM2AMD Athlon 64 X2 Dual-Core4050e (G2)(45W)2100MHz512KBx2
Socket AM2AMD Athlon 64 X2 Dual-Core4000+ (G1)(65W)2100MHz512KBx2
Socket AM2AMD Athlon 64 X2 Dual-Core4000+ (F2)(89W)2000 MHz1MBx2
Socket AM2AMD Athlon 64 X2 Dual-Core4000+ (F2)(65W)2000MHz1MBx2
Socket AM2AMD Athlon 64 X2 Dual-Core3800+ (F3)(65W)2000 MHz512KBx2
Socket AM2AMD Athlon 64 X2 Dual-Core3800+ (F2)(89W)2000MHz512KBx2
Socket AM2AMD Athlon 64 X2 Dual-Core3800+ (F2)(65W)2000 MHz512KBx2
Socket AM2AMD Athlon 64 X2 Dual-Core3800+ (F2)(35W)2000MHz512KBx2
Socket AM2AMD Athlon 64 X2 Dual-Core3600+ (G1)(65W)1900MHz512KBx2
Socket AM2AMD Athlon 64 X2 Dual-Core3600+ (F2)(65W)2000MHz512KBx2
Socket AM3AMD Phenom™ II Quad-Core960T (E0) (95W)3000 MHz512KB X 4
Socket AM3AMD Phenom™ II Quad-Core945 (C3) (95W)3000 MHz512KB X 4
Socket AM3AMD Phenom™ II Quad-Core945 (C2) (95W)3000 MHz512KB X 4
Socket AM3AMD Phenom™ II Quad-Core925 (C3) (95W)2800 MHz512KB X 4
Socket AM3AMD Phenom™ II Quad-Core925 (C2) (95W)2800 MHz512KB X 4
Socket AM3AMD Phenom™ II Quad-Core910e (C3) (65W)2600 MHz512KB X 4
Socket AM3AMD Phenom™ II Quad-Core910 (C2) (95W)2600 MHz512KB X 4
Socket AM3AMD Phenom™ II Quad-Core905e (C3) (65W)2500MHz512KB x 4
Socket AM3AMD Phenom™ II Quad-Core905e (C2) (65W)2500Mhz512KB X 4
Socket AM3AMD Phenom™ II Quad-Core900e (C2) (65W)2400 MHz512KB X 4
Socket AM3AMD Phenom™ II Quad-Core840T (E0) (95W)2900MHz512KB X 4
Socket AM3AMD Phenom™ II Quad-Core840 (L2) (95W)3.3GHz512KB X 4
Socket AM3AMD Phenom™ II Quad-Core820 (C2) (95W)2800Mhz512KB X 4
Socket AM3AMD Phenom™ II Quad-Core810 (C2) (95W)2600 MHz512KB X 4
Socket AM3AMD Phenom™ II Quad-Core805 (C2) (95W)2500 MHz512KB X 4
Socket AM3AMD Athlon™ II X4 Quad-Core Processor655 (C3) (95W)3300MHz512KB x 4
Socket AM3AMD Athlon™ II X4 Quad-Core Processor645 (C3) (95W)3100 MHz512KB X 4
Socket AM3AMD Athlon™ II X4 Quad-Core Processor640 (C3) (95W)3000 MHz512KB X 4
Socket AM3AMD Athlon™ II X4 Quad-Core Processor635 (C3) (95W)2900 MHz512KB X 4
Socket AM3AMD Athlon™ II X4 Quad-Core Processor635 (C2) (95W)2900 MHz512KB X 4
Socket AM3AMD Athlon™ II X4 Quad-Core Processor630 (C2) (95W)2800 MHz512KB X 4
Socket AM3AMD Athlon™ II X4 Quad-Core Processor620 (C2) (95W)2600 MHz512KB X 4
Socket AM3AMD Athlon™ II X4 Quad-Core Processor615 (C3) (45W)2500 MHz512KB X 4
Socket AM3AMD Athlon™ II X4 Quad-Core Processor605e(C3)(45W)2300 MHz512KB X 4
Socket AM3AMD Athlon™ II X4 Quad-Core Processor605e (C2) (45W)2300 MHz512KB X 4
Socket AM3AMD Athlon™ II X4 Quad-Core Processor600e (C2) (45W)2200 MHz512KB X 4
Socket AM3AMD Phenom™ II Six-Core1065T (E0) (95W)2900MHz512KB x 6
Socket AM3AMD Phenom™ II Six-Core1045T (E0) (95W)2700MHz512KB X 6
Socket AM2AMD Athlon 64LE1660 (G2)(45W)2800MHz512KB
Socket AM2AMD Athlon 64LE1640 (G2)(45W)2700MHz512KB
Socket AM2AMD Athlon 64LE1640 (F3)(45W)2600MHz512KBX2
Socket AM2AMD Athlon 64LE1620 (F3)(45W)2400MHz512KBX2
Socket AM3AMD Phenom™ II Triple-CoreBlack Edition 740 (C2) (95W)3000 MHz512KB X 3
Socket AM3AMD Phenom™ II Triple-CoreBlack Edition 720 (C2) (95W)2800 MHz512KB X 3
Socket AM2+AMD Phenom Quad-Core9850 (B3) (95W)2500 MHz512KB X 4
Socket AM2+AMD Phenom Quad-Core9750 (B3) (95W)2400 MHz512KBx4
Socket AM2+AMD Phenom Quad-Core9650 (B3) (95W)2300 MHz512KBx4
Socket AM2+AMD Phenom Quad-Core9600 (B2) (95W)2300 MHz512KB x4
Socket AM2+AMD Phenom Quad-Core9550+ (B3) (95W)2200MHz512KB x4
Socket AM2+AMD Phenom Quad-Core9500 (B2) (95W)2200 MHz512KB x4
Socket AM2+AMD Phenom Quad-Core9100e (B2) (65W)1800 MHz512KBx4
Socket AM2+AMD Phenom Triple-Core8850 (B3) (95W)2500 MHz512KB X 3
Socket AM2+AMD Phenom Triple-Core8750 (B3) (95W)2400MHz512KB x3
Socket AM2+AMD Phenom Triple-Core8650 (B3) (95W)2300MHZ512KB x3
Socket AM2+AMD Phenom Triple-Core8600 (B2) (95W)2300MHz512KB x3
Socket AM2+AMD Phenom Triple-Core8450 (B3) (95W)2100MHz512KB x3
Socket AM2+AMD Phenom Triple-Core8400 (B2) (95W)2100MHz512KB x3
Socket AM2+AMD Phenom Triple-Core8250e (B3) (65W)1900 MHz512KB X 3
Socket AM3AMD Phenom™ II Triple-Core720 (C2)(95W)2800 MHz512KB X 3
Socket AM3AMD Phenom™ II Triple-Core710 (C2) (95W)2600 MHz512KB X 3
Socket AM3AMD Phenom™ II Triple-Core705e (C2) (65W)2500 MHz512KB X 3
Socket AM3AMD Phenom™ II Triple-Core700e (C2) (65W)2400 MHz512KB X 3
Socket AM3AMD Athlon™ II X3 Triple-Core Processor460 (C3) (95W)3400MHz512KB x 3
Socket AM3AMD Athlon™ II X3 Triple-Core Processor450 (C3) (95W)3200 MHz512KB X 3
Socket AM3AMD Athlon™ II X3 Triple-Core Processor445 (C3) (95W)3100 MHz512KB X 3
Socket AM3AMD Athlon™ II X3 Triple-Core Processor440 (C3) (95W)3000 MHz512KB X 3
Socket AM3AMD Athlon™ II X3 Triple-Core Processor440 (C2) (95W)3000 MHz512KB X 3
Socket AM3AMD Athlon™ II X3 Triple-Core Processor435 (C3) (95W)2900 MHz512KB X 3
Socket AM3AMD Athlon™ II X3 Triple-Core Processor435 (C2) (95W)2900 MHz512KB X 3
Socket AM3AMD Athlon™ II X3 Triple-Core Processor425 (C2) (95W)2700Mhz512KB X 4
Socket AM3AMD Athlon™ II X3 Triple-Core Processor420 (C3) (45W)2600 MHz512KB X 3
Socket AM3AMD Athlon™ II X3 Triple-Core Processor405e(C3)(45W)2300 MHz512KB X 3
Socket AM3AMD Athlon™ II X3 Triple-Core Processor405e (C2) (45W)2300 MHz512KB X 3
Socket AM3AMD Athlon™ II X3 Triple-Core Processor400e (C2) (45W)2200 MHz512KB X 3
Socket AM2AMD Athlon 644000+ (F3)(62W)2600MHz512KB
Socket AM2AMD Athlon 644000+ (F2)(62W)2600MHz512KB
Socket AM2AMD Athlon 643800+ (G1)(45W)2400 MHz512KB
Socket AM2AMD Athlon 643800+ (F3)(62W)2400MHz512KB
Socket AM2AMD Athlon 643800+ (F2)(62W)2400 MHz512KB
Socket AM2AMD Athlon 643500+ (G1)(45W)2200MHz512KB
Socket AM2AMD Athlon 643500+ (F3)(62W)2200MHz512KB
Socket AM2AMD Athlon 643500+ (F2)(62W)2200 MHz512KB
Socket AM2AMD Athlon 643500+ (F2)(35W)2200MHz512KB
Socket AM2AMD Athlon 643200+ (G1)(45W)2000 MHz512KB
Socket AM2AMD Athlon 643200+ (F2)(62W)2000MHz512KB
Socket AM2AMD Athlon 643000+ (F2)(62W)1800MHz512KB
Socket AM3AMD Phenom™ II Dual-Core570 (C3) (80W)3500MHz512KB x 2
Socket AM3AMD Phenom™ II Dual-Core560 (C3) (80W)3300MHz512KB X 2
Socket AM3AMD Phenom™ II Dual-Core555 (C3) (80W)3200 MHz512KB X 2
Socket AM3AMD Phenom™ II Dual-Core550 (C3) (80W)3100MHz512KB X 2
Socket AM3AMD Phenom™ II Dual-Core550 (C2) (80W)3100MHz512KB X 2
Socket AM3AMD Phenom™ II Dual-Core545 (C3) (80W)3000 MHz512KB X 2
Socket AM3AMD Phenom™ II Dual-Core545 (C2) (80W)3000MHz512KB X 2
Socket AM3AMD Athlon™ II X2 Dual-Core Processor275 (C3) (65W)3500MHz1MB x 2
Socket AM3AMD Athlon™ II X2 Dual-Core Processor265 (C3) (65W)3300 MHz1MB X 2
Socket AM3AMD Athlon™ II X2 Dual-Core Processor260u (C3) (25W)1800 MHz1MB x 2
Socket AM3AMD Athlon™ II X2 Dual-Core Processor260u (C3) (25W)1800 MHz512KB x 2
Socket AM3AMD Athlon™ II X2 Dual-Core Processor260 (C3) (65W)3200 MHz1MB x 2
Socket AM3AMD Athlon™ II X2 Dual-Core Processor255 (C3) (65W)3100 MHz1MB x 2
Socket AM3AMD Athlon™ II X2 Dual-Core Processor255 (C2) (65W)3100MHz1MB X 2
Socket AM3AMD Athlon™ II X2 Dual-Core Processor250 (C3) (65W)3000 MHz1MB x 2
Socket AM3AMD Athlon™ II X2 Dual-Core Processor250 (C2) (65W)3000 MHz1MB X 2
Socket AM3AMD Athlon™ II X2 Dual-Core Processor245 (C3) (65W)2900 MHz1MB x 2
Socket AM3AMD Athlon™ II X2 Dual-Core Processor245 (C2) (65W)2900 MHz1MB X 2
Socket AM3AMD Athlon™ II X2 Dual-Core Processor240e (C2) (45W)2800 MHz1MB X 2
Socket AM3AMD Athlon™ II X2 Dual-Core Processor240 (C2) (65W)2800 MHz1MB X 2
Socket AM3AMD Athlon™ II X2 Dual-Core Processor235e (C2) (45W)2700Mhz512KB X 2
Socket AM3AMD Athlon™ II X2 Dual-Core Processor225 (C3) (65W)2900 MHz1MB X 2
Socket AM3AMD Athlon™ II X2 Dual-Core Processor215 (C2) (65W)2700 MHz1MB X 2
Socket AM2AMD SempronLE-1300 (G2)(45W)2300 MHz512KB
Socket AM2AMD SempronLE-1250 (G2)(45W)2200 MHz512KB
Socket AM2AMD SempronLE-1200 (G2) (45W)2100 MHz512KB
Socket AM2AMD SempronLE-1200 (G1)(45W)2100 MHz512KB
Socket AM2AMD SempronLE-1150 (G1)(45W)2000 MHz256KB
Socket AM2AMD SempronLE-1100 (G1)(45W)1900 MHz256KB
Socket AM2AMD Sempron3800+(F2)(62W)2200 MHz256KB
Socket AM2AMD Sempron3600+ (F2)(62W)2000 MHz256KB
Socket AM2AMD Sempron3500+ (F2)(62W)2000 MHz128KB
Socket AM2AMD Sempron3500+ (F2)(35W)2000 MHz128KB
Socket AM2AMD Sempron3400+ (F2)(62W)1800 MHz256KB
Socket AM2AMD Sempron3400+ (F2)(35W)1800 MHz256KB
Socket AM2AMD Sempron3200+ (F2)(62W)1800 MHz128KB
Socket AM2AMD Sempron3200+ (F2)(35W)1800 MHz128KB
Socket AM2AMD Sempron3000+ (F2)(62W)1600 MHz256KB
Socket AM2AMD Sempron3000+ (F2)(35W)1600MHz256KB
Socket AM2AMD Sempron2800+ (F2)(62W)1600 MHz128KB
Socket AM2AMD Sempron™ Dual-Core2300 (G2) (65W)2200MHz256KB x2
Socket AM2AMD Sempron™ Dual-Core2200 (G2) (65W)2000MHz512KB
Socket AM2AMD Sempron™ Dual-Core2200 (G2) (65W)2000MHz256KBx2
Socket AM2AMD Sempron™ Dual-Core2100 (G2) (65W)1800 MHz256KBx2
Socket AM2AMD Sempron™ Dual-Core2100 (G1) (65W)1800 MHz256KBx2
Socket AM3AMD Sempron150 (C3) (45W)2900MHz1MB
Socket AM3AMD Sempron140 (C2) (45W)2700 Mhz1MB
Socket AM2AMD Athlon X2 Dual-CoreBE-2400 (G2)(45W)2300 MHz512KBx2
Socket AM2AMD Athlon X2 Dual-CoreBE-2350 (G2)(45W)2100 MHz512KBx2
Socket AM2AMD Athlon X2 Dual-CoreBE-2350 (G1)(45W)2100 MHz512KBx2
Socket AM2AMD Athlon X2 Dual-CoreBE-2300 (G2)(45W)1900 MHz512KBx2
Socket AM2AMD Athlon X2 Dual-CoreBE-2300 (G1)(45W)1900 MHz512KBx2
