Emachines RC410 Motherboard 4001211

We apologize but this item is currently unavailable. Please feel free to browse our website for other available items.
Emachines Rc410 Motherboard 4001211
  Enlarge
*Note this image is for descriptional purposes.
Actual product may vary.
Item Code MB4EMAC4001211
Brand Emachines
Model 4001211
Category Intel Lga775 Motherboards

Description

eMachines / Gateway RC410 Socket LGA775 800FSB Motherboard. ECS Raises The Bar Of PC Industry And Deliver A Full-value, High-performance Solution For Today's Most Demanding Tasks.

Part Number: 4001211

Specifications:

Motherboard description Motherboard manufacturer's name: ECS RC410
CPU/Processor Socket: 775
Supports the following processors:
Pentium D 900 series Dual Core (Presler)
Pentium D 800 series Dual Core (Smithfield)
Pentium 4 500 (Prescott)
Pentium 4 600 (Prescott)
Celeron D (Prescott)
Celeron D (Cedar Mill)
Front-side bus (FSB) 800/533 MHz
Chipset Northbridge: ATI RC410
Southbridge: ATI IXP450
BIOS features AMI BIOS
Form factor Micro ATX size form factor, 9.6 in x 9.6 in
Memory Single-channel memory architecture
2 x 240-pin DIMM sockets support unbuffered non-ECC 400/533 MHZ DDR2 memory modules
Maximum eMachines approved memory is 2 GB
Expansion slots Three PCI
One PCI Express
Video graphics Integrated
Supports PCI Express x16 graphics cards
Onboard audio or audio card Built-in Azalia 8 channel audio
Realtek ALC882 or ALC883 8-channel High Definition Audio CODEC
Onboard LAN Realtek RTL8100 10/100 Mbps Fast Ethernet controller
Back panel I/O PS/2 keyboard (purple)
PS/2 mouse (green)
One SPDIF out port
One S-video out port
One VGA out port
One Parallel port
Four USB (2.0)
One RJ-45 networking port (LAN)
FireWire port
Audio ports:
line in (light blue)
line out (lime)
microphone (pink)
side speaker out (gray)
rear speaker out (black)
center/subwoofer (yellow orange)
Internal connectors Two IDE connectors
One floppy drive connector
One ATX 24-pin power connector
One ATX 4-pin +12v power connector
Four Serial ATA connectors
One VGA connector
One CPU fan connector
One PC fan connector
One CD_IN connector
One front panel audio connector
One PC panel connector
Two USB connectors supporting 2.0 ports
