EMC 1000W Power Supply 078-000-062
We apologize but this item is currently unavailable. Please feel free to browse our website for other available items.
Item Code PWRSPLDELLTJ166
Brand Emc
Model PH-0TJ166 078-000-062
Category Emc Power Supplies
Condition Like New Grade A
Condition Description Please note, these power supplies were removed from brand new / overstock servers. They have minor scuffs and scratches from disassembly process, but are fully operational and function as intended!
Description
EMC AX4-2 CX CX3 Series 1000W Standby Power Supply 078-000-062 TJ166 0TJ166 PH-0TJ166 API1FS18. This EMC 1000W Standby Power Supply Unit is used by the original EMC CX series as well as the EMC CX3 series (excluding the CX3-80), AX4 and AX150 series.
EMC Part Number: 078-000-062
Dell Part Number: TJ166 0TJ166 PH-0TJ166
API Part Number: API1FS18
Compatible Part Numbers: 9T610 100-809-013
Compatible Models: EMC AX4-5 CX200 CX3-10 CX3-20 CX3-40 CX3-80 CX300 CX400 CX500 CX600 CX700 DAE2 DAE2P NX4
Specifications:
Input:
100-240V ~ 1Ф 10.2 - 4.3A
50-60Hz
Output:
- Backup: 200VDC --- 1000W 5.A
- Standby: 1000VA - 1000W
Dimensions (W x L x H): 40mm x 605mm x 210mm
