Fardriver 48-72V DC Controller ND72260

Power Input: 48-72V 80A

Color: Green

Type: E-Bike Controller

Features: Fardriver Controller 80A: Sine wave controller designed for brushless DC motors equipped with Hall sensors. This 72V controller comes pre-programmed for the MY1020 72V 3000W motor. To use with different motors requires programming experience and compatibility setup (approx. 2-3 hours) - this is NOT a plug-and-play controller. Designed for MY1020 Brushless Motor, QS Motors, and experienced users with programming skills. Programmable BLDC Controller: 72v brushless controller, there is no need to connect an external bluetooth dongle. The Fardriver app is compatible with both Apple and Android. Android users can find out how to download it in the detailed description, while Apple users search for Fardriver in the app store. Electric Motorcycle Controller Parameter: 72V 3000W controller with waterproofing grade IP67, suitable for 2-3kw Brushless motors Hall. Rated Voltage 72V, the peak voltage is 88V, the label on the controller is 72V, but it is suitable for 48V-72V, rated power: 2KW-3KW, Max DC Current 80A, Phase current 260A, Net Weight 1KG. Please carefully compare whether the size of the product is suitable for your project to avoid installation problems. Electric Dirt Bike Upgrade: All the raw materials are imported, using high-performance Moss tube With the aluminum substrate scheme, the Moss tube is laid on the aluminum substrate and then placed on the PCB board. If the ignition lock is not connected, please connect the E-Lock orange wire to the positive pole, otherwise there will be no power. Advanced Features and Compatibility: Small in size, High efficiency, low temperature rise, small running current With self-learning function, excellent commonality, With flux weakening function. It is suitable for electric Motorcycle Motor and other type Motors. The controller is equipped with a buzzer to indicate the status of the controller. High Power Performance: Delivers up to 260A phase current with 80A maximum DC current, providing powerful acceleration and torque for electric motorcycles, dirt bikes, and scooters with 2000W to 3000W brushless motors.
