FOXCONN A7DA-S 3.0 AM3 AMD No I/O shield

We apologize but this item is currently unavailable. Please feel free to browse our website for other available items.
  Enlarge
Foxconn A7da-S 3.0 Am3 Amd No I/O Shield
Foxconn A7da-S 3.0 Am3 Amd No I/O Shield
Foxconn A7da-S 3.0 Am3 Amd No I/O Shield
*Note this image is for descriptional purposes.
Actual product may vary.
Item CodeMB64FOXCA7DAS3N
BrandFoxconn
ModelA7DA-S 3.0 Version 1.0
CategoryAmd Socket Am2+ Am3 Motherboards
ConditionLike New Grade A
Condition DescriptionPlease Note: This is an OEM motherboard and it does not come with rear I/O shield also known as back-plate cover; this part is not needed and you can still install the board in standard ATX case. No other accessories!

Description

Foxconn A7DA-S 3.0 AMD 790GX Socket AM3 HDMI ATX Motherboard. Part of the Performance series of motherboards, the A7DA-S 3.0 offers enhanced connectivity and entertainment capability, backed-up by high-performance features and components. Based on the AMD 790GX and SB750 chipset with an advanced DirectX 10 graphics engine with AMD UVD technology. UVD supports Blue-Ray and HD-DVD content, whilst offloading power and processor-intensive video decoding from the CPU to the graphics core. Side port memory is supported and does increase performance a good deal. Supporting AMD the latest Phenom II processors with HT3.0 technology and supports Dual DDR3 1333MHz memory for better overall system performance.2* PCIe Gen2.0 x16 slots are provided, enabling support for ATI CrossFireX technology and ATI Hybrid graphics technology - which boosts your system performance by enabling the ability for both discrete graphics and integrated graphics to render simultaneously. The A7DA-S 3.0 is designed for supporting Foxconn unique green (GSM) technology.







Features:
  • AMD Phenom II processor, Socket AM3
  • Supports Socket AM3 with HT3.0 interface
  • 5.2 GT/s HyperTransport
  • 128MB DDR3 1333 Side Port Memory onboard
  • Dual channel DDR3 1333/1066/800 x 4 DIMMs, Max. 8GB
  • 2 x PCIe2.0 x16, 2 x PCIe2.0 x1, 2 x PCI
  • 1 x ATA133, 2 x 1394a, 6 x SATA II (one supports eSATA)
  • 7.1 channel HDA, Realtek ALC888-GR
  • Gigabit LAN, Broadcom BCM5784
  • 12 USB 2.0 ports







Specifications:

Processor: AMD Phenom II processor, Socket AM3
Chipset: AMD 790GX + SB750
Front Side Bus: 5.2 GT/s HyperTransport
Memory: Dual channel DDR3 1333/1066/800 x 4 DIMMs, Max. 8GB
VGA on Die: ATI Radeon HD3300
Expansion Slots: 2x PCIe2.0 x16, 2x PCIe2.0 x1, 2x PCI
IDE: 1x ATA133
Serial ATA (SATA)/RAID: 5x SATAII + 1x eSATA w / RAID 0, 1, 10, 5, JBOD
Audio: 7.1 channel HDA by Realtek ALC888-GR
LAN: Gigabit LAN by Broadcom BCM5784
IEEE1394: 2x 1394a
Back Panel I/O Ports:
1 x PS/2 keyboard port
1 x VGA port
1 x IEEE1394a port
1 x HDMI port
1 x DVI-D port
1 x Audio jack supports 6 jacks
6 x USB 2.0 ports
1 x RJ45 LAN port
1 x S/PDIF OUT port
Internal I/O Connectors:
1 x ATX 24-Pin power connector
1 x 8-pin ATX 12V power connector
1 x 4-pin ATX 12V power connector
3 x 4-pin CPU / System / NB FAN connectors
1 x Floppy disk drive connector
1 x CD-in connector
1 x Front Audio Header
1 x COM1 header
1 x IrDA header
3 x USB 2.0 headers support additional 6 ports
2 X onboard Power-on/Rest buttons
1 x ATA133 IDE connector
5 x Serial ATAII connectors
1 x eSATA connector
1 x Intrusion Alarm header
1 x Front Panel header
1 x IEEE1394a connector
1 x Speaker
BIOS Features: 8Mb flash EEPROM w/ LAN boot PnP, ACPI, WfM,
Standards/Manageability: PCI 2.3, USB2.0, DMI 2.5
Form Factor: ATX (12" x 9.6")







CPU Compatibility for A7DA-S 3.0:

CPU NameCoreCpu No.FSB (Mhz)Wattage
 AM3 AthlonII  2.0G Sargas170U1024KB20W
 AM3 AthlonII×2  2.7G Regor235E1024KB*245W
 AM3 AthlonII×2  2.8G Regor240E1024KB*245W
 AM3 AthlonII×2  2.9G Regor245E1024KB*245W
 AM3 AthlonII×2  3.0G Regor250E1024KB*245W
 AM3 AthlonII×2  2.7G RegorX215512KB*265W
 AM3 AthlonII×2  2.7G TBDX215512KB*265W
 AM3 AthlonII×2  2.8G RegorX220512KB*265W
 AM3 AthlonII×2  2.8G RegorX2401024KB*265W
 AM3 AthlonII×2  2.9G RegorX2451024KB*265W
 AM3 AthlonII×2  3.0G RegorX2501024KB*265W
 AM3 AthlonII×2  3.1G RegorX2551024KB*265W
 AM3 AthlonII×2  3.2G RegorX2601024KB*265W
 AM3 AthlonII×4  2.2G Propus600E512KB×445W
 AM3 AthlonII×4  2.3G Propus605E512KB×445W
 AM3 AthlonII×4  2.4G Propus610E512KB×445W
 AM3 AthlonII×4  2.6G PropusX620512KB×495W
 AM3 AthlonII×4  2.8G PropusX630512KB×495W
 AM3 AthlonII×4  2.9G PropusX635512KB×495W
 AM3 AthlonII×4  3.0G PropusX640512KB×495W
 AM3 AthlonIIx3  2.2G Rana400E512KB×345W
 AM3 AthlonIIx3  2.3G Rana405E512KB×345W
 AM3 AthlonIIx3  2.5G Rana415E512KB×345W
 AM3 AthlonIIx3  2.7G RanaX425512KB×395W
 AM3 AthlonIIx3  2.9G RanaX435512KB×395W
 AM3 AthlonIIx3  3.0G RanaX440512KB×395W
 AM3 AthlonIIx3  3.1G RanaX445512KB×395W
 AM3 PhenomII×2  3.0G CallistoX545512KB*280W
 AM3 PhenomII×2  3.1G CallistoX550512KB*280W
 AM3 PhenomII×2  3.1G CallistoZ550512KB*280W
 AM3 PhenomII×2  3.2G CallistoZ555512KB*280W
 AM3 PhenomII×3  2.4G Heka700E512KB*365W
 AM3 PhenomII×3  2.5G Heka705E512KB*365W
 AM3 PhenomII×3  2.6G HekaX710512KB*395W
 AM3 PhenomII×3  2.8G HekaX720512KB*395W
 AM3 PhenomII×3  2.8G HekaZ720512KB*395W
 AM3 PhenomII×3  3.0G HekaZ740512KB*395W
 AM3 PhenomII×4  2.4G Deneb900E512KB×465W
 AM3 PhenomII×4  2.5G Deneb905E512KB×465W
 AM3 PhenomII×4  2.5G DenebX805512KB×495W
 AM3 PhenomII×4  2.6G DenebX810512KB×495W
 AM3 PhenomII×4  2.8G DenebX820512KB×495W
 AM3 PhenomII×4  2.6G DenebX910512KB×495W
 AM3 PhenomII×4  2.8G DenebX925512KB×495W
 AM3 PhenomII×4  3.0G DenebX945512KB×4125W
 AM3 PhenomII×4  3.0G DenebX945512KB×495W
 AM3 PhenomII×4  3.2G DenebX955512KB×4125W
 AM3 PhenomII×4  3.2G DenebX955512KB×495W
 AM3 PhenomII×4  3.2G DenebZ955512KB×4125W
 AM3 PhenomII×4  3.2G DenebZ955512KB×495W
 AM3 PhenomII×4  3.4G DenebZ965512KB×4140W
 AM3 PhenomII×6  2.6G ThubanT35T512KB×695W
 AM3 PhenomII×6  2.8G ThubanT55T512KB×6125W
 AM3 PhenomII×6  2.8G ThubanT55T512KB×695W
 AM3 PhenomII×6  3.2G ThubanT90Z512KB×6125W
 AM3 Sempron  2.7G SargasX1401024KB45W
 AM3 Sempron  2.8G SargasX1451024KB45W
 AM3 Sempron  2.4G SargasX180512KB45W
