Foxconn A85GM AM3 785G DDR2 Motherboard

Foxconn A85GM AM3/AM2+/AM2 AMD 785G HDMI Micro ATX AMD Motherboard. Part of the Performance series of motherboards, the A85GM offers enhanced connectivity and entertainment capability, backed-up by high-performance features and components. Based on the AMD® 785G and SB710 chipset with an advanced DirectX 10.1 graphics engine with AMD® UVD technology. Supporting the latest 140W CPU with 5.2GT/S Hyper Transport, the A85GM allows you to build powerful PCs on a budget. Supporting up to 8GB of Dual Channel DDR2 memory at 1066MHz. Gigabit LAN and 8-channel HD audio are included onboard. The A85GM is designed for high-performance systems and supports Dual DDR2 1066MHz memory for better overall system performance.



Features:

• AMD Phenom II, Phenom, Athlon ,Sempron processors
• Supports Socket AM3/AM2+ with HT3.0 interface
• 5.2 GT/s HyperTransport
• Dual channel DDR2 1066/800/667x 4 DIMMs, Max 8GB
• 1* PCIe 2.0 x16, 1* PCIe 2.0 x1, 2* PCI
• ATA 133 x 1, SATAII x 5, eSATA x 1
• 7.1 channel HD Audio
• Gigabit LAN
• 10 USB 2.0 ports



Specifications:

Processor: AMD Phenom II, Phenom, Athlon, Sempron processors, Socket AM3 and AM2+.
Chipset: AMD 785G + SB710
Front Side Bus: 5.2 GT/s HyperTransport
Memory: Dual channel DDR2 1066/800/667 x 4 DIMMs, Max. 8GB
VGA on Die: Integrated ATI Radeon HD4200
Expansion Slots: 1* PCIe 2.0 x16, 1* PCIe 2.0 x1, 2* PCI
IDE: ATA 133 * 1
Serial ATA(SATA)/RAID: SATAII * 5 w / RAID 0, 1, 10
Audio: 7.1 channel HD Audio by Realtek ALC888-GR
LAN: Gigabit LAN by Broadcom® BCM5784MB0KMLG
Back Panel I/O Ports:
1 x PS/2 keyboard port
1 x PS/2 mouse port
1 x VGA port
1 x DVI-D port
1 x Audio jack supports 6 jacks
6 x USB 2.0 ports
1 x RJ45 LAN jack
1 x HDMI port
Internal I/O Connectors:
1 x ATX 24-pin power connector
1 x 4-pin ATX 12V power connector
3 x 4-pin CPU/System Fan connectors
1 x Floppy connector
1 x CD-in connector
1 x Front Audio header
1 x Front Panel header
1 x IrDA header
2 x USB 2.0 connectors support additional 4 ports
5 x SATAII connectors
1 x eSATA connector
1 x ATA133 IDE connector
1 x Intrusion Alarm header
1 x COM1 header
1 x Speaker header
1 x S/PDIF Out header
BIOS Features: 8Mb flash EEPROM w/ LAN boot PnP, ACPI, WfM, DMI
Standards/Manageability: PCI 2.3, USB2.0, DMI 2.5
Special Features:
Supports ATI Hybrid graphics technology
ATI Radeon HD4200 graphics engine
Supports DirectX 10.1
Supports AMD UVD, Unified Video Decoder (H/W decoder for H.264,
VC-1 and mpeg-2 video formats)
Supports HDMI/DVI/HDCP
Form Factor: Micro ATX ( 9.6" x 9.6")
