FOXCONN A9DA-S 890GX AM3 DDR3 SATA3 HDMI

Foxconn A9DA-S AM3 AMD 890GX HDMI SATA 6Gb/s ATX Motherboard. Part of the Performance series of motherboards, the A9DA-S offers enhanced connectivity and entertainment capability, backed-up by high-performance features and components. Based on the AMD® 890GX and SB850 chipset with an advanced DirectX 10.1 graphics engine with AMD UVD 2.0 technology. UVD supports Blue-Ray and HD-DVD content, whilst offloading power and processor-intensive video decoding from the CPU to the graphics core. Side port memory is supported and does increase performance a good deal. Supporting AMD the latest Phenom™II processors with HT3.0 technology.and supports Dual DDR3 1600MHz(overclocking) memory for better overall system performance.2* PCIe Gen2.0 x16 slots are provided, enabling support for ATI CrossFireX™ technology and ATI™ Hybrid graphics technology - which boosts your system performance by enabling the ability for both discrete graphics and integrated graphics to render simultaneously. The A9DA-S is designed for supporting Foxconn unique green(GSM & GOD) technology.




Features:

• AMD Phenom II, Athlon II processors ,Supports Socket AM3 with HT3.0 interface
• 4.8GT/s HyperTransport
• Dual channel DDR3 1600(oc)/1333/1066 x 4 DIMMs, Max 16GB
• 2x PCIe 2.0 x16, 2x PCIe 2.0 x1, 2x PCI
• IEEE1394a x 2
• SATAIII x 5, eSATA x 1
• 7.1 channel HD Audio
• Gigabit LAN
• 14 USB 2.0 ports


Specifications:

Processor: AMD Phenom II, Athlon II processors, Socket AM3.
Chipset: AMD 890GX + SB850
Front Side Bus: 4.8 GT/s HyperTransport
Memory: Dual channel DDR3 1600(oc)/1333/1066 x 4 DIMMs, Max. 16GB
VGA: Integrated ATI Radeon HD4290
Expansion Slots: 2x PCIe 2.0 x16, 2x PCIe 2.0 x1, 2x PCI
Serial ATA (SATA)/RAID: SATAIII * 5 + eSATA * 1 w / RAID 0, 1, 10, 5
Audio: 7.1 channel HD Audio
LAN: Gigabit LAN
IEEE1394: IEEE1394a * 2
Back Panel I/O Ports:
1 x PS/2 keyboard port
1 x IEEE1394a port
1 x VGA port
1 x HDMI port
1 x DVI-D port
1 x Audio jack supports 6 jacks
6 x USB 2.0 ports
1 x RJ45 LAN port
1 x S/PDIF OUT port
Internal I/O Connectors:
1 x ATX 24-Pin power connector
1 x 8-pin ATX 12V power connector
3 x 4-pin CPU / System / NB FAN connectors
1 x CD-in connector
1 x Front Audio Header
1 x COM header
1 x Speaker
4 x USB 2.0 headers support additional 8 ports
2 x onboard Power-on/Rest buttons
5 x Serial ATAIII connectors
1 x eSATA connector
1 x Front Panel header
1 x COM header
BIOS Features: 16Mb flash EEPROM w/ LAN boot PnP, ACPI, WfM, DMI
Special Features:
* Based on AMD 890GX chipset with AOD Extreme & SB850 Southbridge
* 2* PCIe x16 Gen2.0 with ATI CrossFireX™ and Hybrid Graphics™ support
* onboard side port memory-128MB DDR3 1333 support, with graphics performance increasing over 15%
* Dual Channel DDR3 1600MHz(overclocking) support with AM3 socket Phenom™II processors
* 100% SOLID Capacitor design and Ferrite Choke power delivery ensure a stable basis for overclocking and increased reliability
* Fully supports AMD OverDrive™ utility for overclocking, system monitoring and testing.
Form Factor: ATX ( 12.0" x 9.6")
