Gateway GS-400 Rack Mounting Server 1U

We apologize but this item is currently unavailable. Please feel free to browse our website for other available items.
Gateway Gs-400 Rack Mounting Server 1U. Model: Gs-400 7003503
  Enlarge
*Note this image is for descriptional purposes.
Actual product may vary.
Item Code RMSGATGS4001U
Brand Gateway
Model GS-400 7003503
Category Rackmount 1U Servers

Description

Gateway GS-400 Rack Mounting Server 1U. The Gateway GS-400 is a storage server that uses a customized Linux distribution as the default operating system.

Specifications:

System
Dimensions1.7 × 17.6 × 19.00 inches (height × width × depth)
Weight15.5-18 kilograms; 34-40 pounds (estimated)
Regulatory ApprovalsUL 1950, CE Mark, TUV, FCC Class A, VCCI Class I, EN 55022 Class A
Power120-240 VAC Auto Ranging, 50-60 Hz Auto Selecting, 150-Watts Maximum, PFC
MotherboardMicroATX form factor with an Intel™ 815 Chipset and a low profile PCI option slot
Processor566 megahertz Celeron
System Memory2 DIMM slots populated with 64 megabytes of SDRAM
NAS Operating SystemConnexOS 2.0 (Linux)
Front PanelSoft Power On/Shutdown/Power Off Button (recessed)
4 LEDs: Pwr On, Network, Drive Activity, System Fault
Drive Fault LEDs (one on each drive carrier)
Snap on Front Cover with Key Lock
Rear panelMain Power On/Off Switch
10/100 ethernet port (RJ45)
9-pin D type serial port
2 USB ports
Low profile PCI option slot
VGA and Parallel port are not supported
Power SupplySingle module, fixed
Cooling Fans3 (N+1), Hot-pluggable
Rack Mount OptionsRack mount kit (mounting brackets, cable constraints)
Storage
Drive Bays4 removable, 1-inch IDE hard disk drive bays - (Not Included)
Supported Hard Drives40 gigabyte (GB) or 60 GB (Not Included)
Maximum Raw Capacity160 GB using 40 GB drives (4 x 40GB) (Not Included)
240 GB using 60 GB drives (4 x 60GB) (Not Included)
Disk/Volume Management
(Software RAID)		Linear Disk/Group (No RAID)
RAID Level 0
RAID Level 1
RAID Level 5
Hot spare support
Advanced Storage ServicesMulti-volume management
N-Way mirroring
Journaling file system
User quotas
Network
Network ProtocolTCP/IP, IPX, NetBEUI, Appletalk
Network InterfaceSingle 10/100 Base-T Ethernet
File Sharing ProtocolsCIFS
NFS v2.0 & 3.0
NCP
AFP (Apple File Protocol)
Network SecuritySID, ACL (Access Control Lists)
Full NT domain integration
NIS (UNIX)
Other Network ServicesNDS
HTTP
FTP
DHCP - (limited)
Manageability and Serviceability
Front Panel LEDsDrive Activity LED
System Power LED
System Fault LED
Network Activity LED
Drive LEDsDrive attention LEDs (one on each drive carrier)
UPS SupportUsing the Serial Port or USB
Remote Management SupportBrowser-based Management Tool
Configuration Management
Security Management
System Health & Status Monitoring
Unit Identification
Software Updating
Event Logging
SMTP (E-Mail) Notification
Multi-NAS Management (NASFinder)
Environmental
Power120-240 VAC Auto Ranging, 50-60 Hz Auto Selecting, 150-Watts Maximum, PFC
Operating Temperature0-400 Centigrade; 32-1080 Fahrenheit @ 20-90%, Relative Humidity (non-condensing)
Non-Operating Temperature-10-500 Centigrade; 14-1220 Fahrenheit @ 10-90%, Relative Humidity (non-condensing)
Part Number7003503
