GIGABYTE GA-Z170X-UD5 Desktop Mboard

We apologize but this item is currently unavailable. Please feel free to browse our website for other available items.
Gigabyte Ga-Z170x-Ud5 Desktop Mboard
  Enlarge
Gigabyte Ga-Z170x-Ud5 Desktop Mboard
Gigabyte Ga-Z170x-Ud5 Desktop Mboard
*Note this image is for descriptional purposes.
Actual product may vary.
Item Code MBDSGAZ170XUD5A
Brand Gigabyte
Model GA-Z170X-UD5
Category Intel Lga1151 Motherboard
Condition Like New Grade A
Condition Description Please note, this motherboard comes with I/O Shield, only! No cables, fan’s bracket, fan’s mounting backplate or any other accessories!

Description

GIGABYTE GA-Z170X-UD5 Intel Chipset Z170 Socket LGA1151 DDR4 HDMI DisplayPort DVI-D SATA 6.0Gb/s ATX Desktop Motherboard.

Chipset: Intel Z170
Socket: Intel LGA1151
Compatible/Supported CPU: Support for 7th/6th Generation Intel Core i7 processors/Intel Core i5 processors/ Intel Core i3 processors/Intel Pentium processors/ Intel Celeron processors
Max Supported Memory: 64GB
Number of Memory Slots: 4
Memory Type: DDR4 SDRAM
Speed: 3466MHz, 3400MHz, 3333MHz, 3300MHz, 3200MHz, 3000MHz, 2800MHz, 2666MHz, 2400MHz, 2133MHz
Storage Interface: SATA 6.0Gb/s
RAID Support: 0, 1, 5, 10
Network/Communications: Intel GbE LAN 10/100/1000Mb/s
Audio: Realtek ALC1150 Codec, High Definition Audio 2/4/5.1/7.1-channel
Connectors: 1x 24-pin ATX main power connector, 1x 8-pin ATX 12V power connector, 2x M.2 Socket 3 connectors, 3x SATA Express connectors, 8x SATA 6Gb/s connectors, 1x CPU fan header, 1x water cooling fan header (CPU_OPT), 3x system fan headers, 1x front panel header, 1x front panel audio header, 1x S/PDIF Out header, 2x USB 3.0/2.0 headers 2x USB 2.0/1.1 headers, 1x Trusted Platform Module (TPM) header, 1x Thunderbolt add-in card connector, 1x serial port header, 1x Clear CMOS jumper, 1x power button, 1x reset button, 1x Clear CMOS button, 1x ECO button, 1x OC button, Voltage measurement points
Input/Output Ports: 2x USB 2.0/1.1 ports, 1x PS/2 keyboard/mouse port, 1x DVI-D port, 1x DisplayPort, 1x HDMI port, 3x USB 3.0/2.0 ports, 1x USB Type-C port, with USB 3.1 support, 1x USB 3.1 Type-A port (red), 2x RJ-45 ports, 1x optical S/PDIF Out connector, 5x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Line In, Line Out, Mic In)
Expansion Slots: 1x PCI Express x16 slot, running at x16, 1x PCI Express x16 slot, running at x8, 1x PCI Express x16 slot, running at x4, 4x PCI Express x1 slots, 2x M.2 Socket 3 connectors
Form Factor: ATX
Type: Desktop Motherboard
Supported Operating System: Windows 10 64-bit, Windows 8.1 64-bit, Windows 7 32-bit/64-bits

Additional Specifications:

Onboard Graphics
Integrated Graphics Processor-Intel HD Graphics support:
1x DVI-D port, supporting a maximum resolution of 1920x1200@60 Hz
The DVI-D port does not support D-Sub connection by adapter.
1x DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz
Support for DisplayPort 1.2 version.
1x HDMI port, supporting a maximum resolution of 4096x2160@24 Hz
Support for HDMI 1.4 version.
Support for up to 3 displays at the same time
Maximum shared memory of 1024MB

Multi-Graphics Technology
Support for NVIDIA Quad-GPU SLI and 2-Way NVIDIA SLI technologies
Support for AMD Quad-GPU CrossFireX and 3-Way/2-Way AMD CrossFire technologies

I/O Controller
iTE I/O Controller Chip

H/W Monitoring
System voltage detection
CPU/System/Chipset temperature detection
CPU/CPU OPT/System fan speed detection
CPU/System/Chipset overheating warning
CPU/CPU OPT/System fan fail warning
CPU/CPU OPT/System fan speed control
Whether the fan speed control function is supported will depend on the cooler you install

BIOS
1.2x 128 Mbit flash
2.Use of licensed AMI UEFI BIOS
3.Support for DualBIOS
4.PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Unique Features
1.Support for APP Center
Available applications in APP Center may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications.
3D OSD
@BIOS
Ambient LED
AutoGreen
Cloud Station
EasyTune
Easy RAID
Fast Boot
Smart TimeLock
Smart Keyboard
Smart Backup
System Information Viewer
USB Blocker
2.Support for Q-Flash
3.Support for Smart Switch
4.Support for Xpress Install



CPU Support:

Socket LGA1151
VendorCPU ModelCPU FrequencyL3 CacheProcessCore NameSteppingWattage
IntelCore i7-7700K4.20GHz8MB14nmKabyLakeB091W
IntelCore i7-77003.60GHz8MB14nmKabyLakeB065W
IntelCore i7-7700T2.90GHz8MB14nmKabyLakeB035W
IntelCore i5-7600K3.80GHz6MB14nmKabyLakeB091W
IntelCore i5-76003.50GHz6MB14nmKabyLakeB065W
IntelCore i5-7600T2.80GHz6MB14nmKabyLakeB035W
IntelCore i5-75003.40GHz6MB14nmKabyLakeB065W
IntelCore i5-7500T2.70GHz6MB14nmKabyLakeB035W
IntelCore i5-74003.00GHz6MB14nmKabyLakeB065W
IntelCore i5-7400T2.40GHz6MB14nmKabyLakeB035W
IntelCore i3-7350K4.20GHz4MB14nmKabyLakeS060W
IntelCore i3-73204.10GHz4MB14nmKabyLakeS051W
IntelCore i3-73004.00GHz4MB14nmKabyLakeS051W
IntelCore i3-7300T3.50GHz4MB14nmKabyLakeS035W
IntelCore i3-71003.90GHz3MB14nmKabyLakeS051W
IntelCore i3-7100T3.40GHz3MB14nmKabyLakeS035W
IntelPentium G46203.70GHz3MB14nmKabyLakeS051W
IntelPentium G46003.60GHz3MB14nmKabyLakeS051W
IntelPentium G4600T3.00GHz3MB14nmKabyLakeS035W
IntelPentium G45603.50GHz3MB14nmKabyLakeB054W
IntelPentium G4560T2.90GHz3MB14nmKabyLakeS035W
IntelCeleron G39503.00GHz2MB14nmKabyLakeS051W
IntelCeleron G39302.90GHz2MB14nmKabyLakeS051W
IntelCeleron G3930T2.70GHz2MB14nmKabyLakeS035W
IntelCore i7-6700K4.00GHz8MB14nmSkylakeR091W
IntelCore i7-67003.40GHz8MB14nmSkylakeR065W
IntelCore i7-6700T2.80GHz8MB14nmSkylakeR035W
IntelCore i5-6600K3.50GHz6MB14nmSkylakeR091W
IntelCore i5-66003.30GHz6MB14nmSkylakeR065W
IntelCore i5-6600T2.70GHz6MB14nmSkylakeR035W
IntelCore i5-65003.20GHz6MB14nmSkylakeR065W
IntelCore i5-6500T2.50GHz6MB14nmSkylakeR035W
IntelCore i5-6402P2.80GHz6MB14nmSkylakeR065W
IntelCore i5-64002.70GHz6MB14nmSkylakeR065W
IntelCore i5-6400T2.20GHz6MB14nmSkylakeR035W
IntelCore i3-63203.90GHz4MB14nmSkylakeS047W
IntelCore i3-63003.80GHz4MB14nmSkylakeS047W
IntelCore i3-6300T3.30GHz4MB14nmSkylakeS035W
IntelCore i3-61003.70GHz3MB14nmSkylakeS047W
IntelCore i3-6100T3.20GHz3MB14nmSkylakeS035W
IntelCore i3-6098P3.60GHz3MB14nmSkylakeR054W
IntelPentium G45203.60GHz3MB14nmSkylakeS047W
IntelPentium G45003.50GHz3MB14nmSkylakeS047W
IntelPentium G4500T3.00GHz3MB14nmSkylakeS035W
IntelPentium G44003.30GHz3MB14nmSkylakeR065W
IntelPentium G44003.30GHz3MB14nmSkylakeS047W
IntelPentium G4400T2.90GHz3MB14nmSkylakeS035W
IntelCeleron G39202.90GHz2MB14nmSkylakeS047W
IntelCeleron G39002.80GHz2MB14nmSkylakeS047W
IntelCeleron G3900T2.60GHz2MB14nmSkylakeS035W
