HannStar 10.1" Laptop LED LCD Screen

HannStar Display model HSD101PFW2-B is a color active matrix thin film transistor (TFT) liquid crystal display (LCD) that uses amorphous silicon TFT as a switching device. This model is composed of a TFT LCD panel, a driving circuit and a back light system. This TFT LCD has a 10.1 (16:9) inch diagonally measured active display area with WSVGA (1024 horizontal by 600 vertical pixel) resolution.

Features:
■ 10.1 (16:9 diagonal) inch configuration
■ One channel LVDS interface
■ 262K color by 6 bit R.G.B signal input
■ RoHS Compliance
■ Halogen Free

Specifications:

Outline Dimension: 235 x 143 x 4.9 (Typ.)
Display area: 222.72(H) x 125.28(V) (10.1” diagonal)
Number of pixel: 1024 (RGB) x 600
Pixel Format: RGB vertical stripe
Pixel pitch: 0.2175(H) x 0.2088(V) (TYP.)
NTSC: 50%
Display Mode: Normally white
Surface treatment: Anti-Glare, Hard-Coating 3H
Power Consumption: 0.65W max. ( Logic )
Backlight: LED
Weight: 450g(Max.)
RoHS Comply: Yes
