IBM ULTRASTAR 36LZX 18.2GB 80-Pin SCSI

IBM Ultrastar 36LZX 18.2GB 1000RPM Ultra 160 80-pin SCSI 3.5 inch hard disk drive. The IBM Ultrastar 36LZX 18.2 GB SCSI Ultra160 (16-bit) Hard Drive is fully compatible with PC system or Servers. The Hard Drive connects by: SCSI Ultra160 (16-bit) 80-Pin for Internal utilization. Spinning up to 10000 RPM and offering capacity as large as 18.2 GB



Features:

Data capacity 18.2 GB
Ultra 160 80 pin
Interleave factor 1:1
Variable Sector Size (512-528 bytes/sector)
Tagged Command Queuing support
Automatic read/write data transfer
4MB segmented sector buffer (128KBx28, 256KBx14 or 512KBx7)
4.9 msec seek time in read operation
Adaptive read ahead algorithm
Write Cache
Back to back write
ECC on the fly
Automatic defect reallocation
Self diagnostics at power on
Closed loop actuator servo
High level of integration of the electronics
Non head disk contact start stop
10000rpm spindle rotation
Automatic actuator lock
PFA (SMART)
Glass substrate disks


Specifications:

Product: IBM Ultrastar Hard Drive 18.2 GB SCSI Hard Drive
Model: DDYS-T18350
Part Number: 07N3240
MLC: DS0S96
Enclosure: Internal
Capacity: 18.2 GB
Buffer Size: 4 MB
Spindle Speed: 10000 RPM
Interface: SCSI Ultra160 (16-bit), Ultra SCSI, Ultra3 SCSI
Platform: PC
External Data Transfer Rate: 160 Mbps
Internal Data Transfer Rate: 56.5 Mbit/s
Form Factor: 3.5", 3.5" x 1/3H (Low Profile)
Seek Time: 4.9 ms
Average Latency: 3 ms
