Intel D975XWT2G1 D33246-108 Motherboard

We apologize but this item is currently unavailable. Please feel free to browse our website for other available items.
Intel D975xwt2g1 D33246-108 Motherboard
  Enlarge
*Note this image is for descriptional purposes.
Actual product may vary.
Item Code MBINTD975XWT2G1
Brand Intel
Model D975XWT2G1 D33246-108
Category Intel Lga775 Motherboards

Description

Intel D975XWT2G1 D33246-108 Motherboard. This Motherboard Support for the LGA775 Intel Pentium 4 and Celeron D processors 1066 or 800 MHz front side bus support.

Part Numbers: D975XWT2G1 D33246-108

Product: Motherboard Only, No Processor Or Fan Included.

Features:

  • Support for the LGA775 Intel Pentium® 4 and Celeron™ D processors
  • 1066 or 800 MHz front side bus support
  • Support for DDR2 667/533 MHz DIMMs providing up to 8 GB of memory
  • Four PCI expansion slots:
    • One PCI Express ×4
    • One PCI Express ×16
    • Two conventional PCI
  • Integrated Intel 82573E GbE Ethernet LAN with Active Management Technology (AMT)
  • Four Serial ATA (SATA) ports
  • Four external USB 2.0 ports with two additional internal headers providing eight optional USB 2.0 ports
  • Three multi-speed system fan headers for CPU and chassis fan control

Specifications:

Form FactoruBTX 6-layer
ChipsetIntel® 975X chipset consisting of:
  • MCH northbridge: Intel D975X (GWD-DG)
  • ICH southbridge: 82801GH (ICH7-DH)
Processor SupportIntel Pentium® 4, Pentium D, or Extreme® processors
  • LGA775 socket
  • 1066 or 800 MHz system bus
Memory Support
  • Four DDR2 SDRAM Dual Inline Memory Module (DIMM) sockets
  • DDR2 667 or DDR2 533 MHz DIMMs
  • Expandable up to 8 GB total memory
    • VideoNo integrated video. An add-in card must be installed.
    AudioIntel High Definition Audio subsystem consisting of:
    • 8-channel (7.1) audio subsystem with five analog audio outputs and one S/PDIF optical digital audio output using the Sigmatel® 9221 audio codec
    LAN SupportIntegrated Intel 82573L (Vidalia) GbE
    Add-in Card Slots
  • One ×16 PCI Express
  • One ×4 PCI Express
  • Two PCI conventional
    • Rear Panel Ports
  • PS/2 keyboard port
  • PS/2 mouse port
  • Four USB 2.0 ports
  • One IEEE-1394a connector
  • One serial port
  • One coaxial S/PDIF (RCA) line out jack
  • One RJ-45 LAN port
  • Five analog audio jacks
  • One S/PDIF optical digital audio jack
    • Peripheral Interfaces
  • Two USB headers (each header supports two connections for a total of four internal connections)
  • Two IEEE-1394a headers
  • Four Serial ATA interfaces
  • One Parallel ATA IDE interface with UDMA 33, ATA-66/100 support
  • One floppy disk drive interface

    • ItemDescriptionItemDescription
    AProcessor fan connectorMStandby power indicator LED
    BMemory slotsNPCI Express x4 connector
    CRear fan connectorOPCI conventional connectors
    DFront panel audio connectorPPCI Express x16 connector
    EBatteryQAdd-In card auxilliary power connector
    FParallel ATA IDE connectorRBIOS configuration jumper
    GSerial ATA connectorsSFront panel IEEE-1394a connectors
    HIntrusion switch connectorTFront panel connector
    IRear panel portsUFront fan connector
    JSpeakerVFloppy disk drive connector
    KInternal USB connectorsWProcessor socket
    LATX main power connectorXProcessor power connector
