Intel Xeon E5-2660 v2 LGA2011 CPU SR1AB
We apologize but this item is currently unavailable. Please feel free to browse our website for other available items.
Item Code CPUINTXNE5SR1AB
Brand Intel
Model Xeon E5-2660 v2
Part Number SR1AB
Series/Family Intel Xeon E5 v2
Category Intel Socket Lga2011 Processors
Condition Like New Grade A
Condition Description Please note, these units were removed from brand new desktop PCs and may show minor signs from the removal process, but are fully operational & function as intended!
Description
Intel Xeon E5-2660 v2 2.2GHz (3GHz Max) 10-Core 2.5MB L2 25MB L3 Cache Socket LGA2011 CPU Processor SR1AB.
Socket: Intel Socket LGA2011
Processor/CPU: Intel Xeon E5-2660 v2
Processor/CPU Speed: 2.20GHz (3.00GHz Max Turbo)
Number of Cores: 10
L2/L3 Cache: 2.5MB L2; 25MB L3.
Max Supported Memory: 768GB
Memory Type: DDR3 800/1066/1333/1600/1866
Error Correction (ECC): Yes
Voltage: 0.65–1.30V
Type: CPU / Microprocessor
Features: QuickPath Interconnect speed is 8 GT/s. Direct Media Interface speed is 5 GT/s. The CPU supports ECC memory. The part supports DDR3-1866 memory. This part supports Turbo Boost Technology. The maximum frequency increase in Turbo Boost mode is 800 MHz for 1 core, 700 MHz for 2 cores, 600 MHz for 3 cores, 500 MHz for 4 cores, and 400 MHz for 5 or more cores.
Additional Specifications:| General information | |
| Vertical Segment | Server |
| Clock multiplier | 22 |
| Package type | 2011-land FC-LGA12A |
| Bus Speed | 8 GT/s |
Memory | |
| Max # of Memory Channels | 4 |
| Max Memory Bandwidth | 59.7 GB/s |
| Physical Address Extensions | 46-bit |
| Expansion Options | |
| Scalability | 2S Only |
| PCI Express Revision | 3.0 |
| PCI Express Configurations ‡ | x4, x8, x16 |
| Max # of PCI Express Lanes | 40 |
| Architecture / Microarchitecture / Other | |
| CPUID | 0306E4h |
| Core stepping | M1 |
| Processor core | Ivy Bridge-EP |
| Manufacturing technology (micron) | 0.022 |
| Number of threads | 20 |
| Features | AES AVX EM64T technology Enhanced SpeedStep technology Execute disable bit Hyper-Threading technology MMX SSE SSE2 SSE3 SSE4 SSSE3 Trusted Execution technology Turbo Boost technology Virtualization technology (VT-d) Virtualization technology (VT-x) |
| Instruction Set | 64-bit |
| Case temperature (°C) | 75 |
| Thermal Design Power (Watt) | 95 |
