NewMar PFM-400 Power Function Manager

We apologize but this item is currently unavailable. Please feel free to browse our website for other available items.
Newmar Pfm-400 Power Function Manager
  Enlarge
Newmar Pfm-400 Power Function Manager
Newmar Pfm-400 Power Function Manager
Newmar Pfm-400 Power Function Manager
*Note this image is for descriptional purposes.
Actual product may vary.
Item Code NEWMARPFMPFM400
Brand Newmar
Model PFM-400
Category Power Controllers
Condition Pre-Owned Grade B
Condition Description Please note, this unit is used and has minor scuffs and scratches, but is fully tested, completely operational and functions as intended. Comes with rack ears only. No cables or any other accessories!

Description

NewMar PFM-400 Power Function Manager. Convert ordinary power supplies (or power modules) into fully integrated, multifunctional power systems with the NewMar PFM-400 Power Function Manager. The NewMar PFM-400 Power Function Manager provides you with control, monitoring, protection, and paralleling of 12, 24, or 48 VDC, with positive, negative, or floating ground power sources.

Model Number: PFM-400







Features:

- Low voltage battery disconnect protects equipment during extended AC power loss.
- Manual battery disconnect allows for service without shutting down the system.
- Anodized aluminum front and side panels.
- Form C alarm contacts allow for remote monitoring.
- For 19" or 23" racks, with 6" forward rackmount brackets included.
- Digital meter displays voltage or current for easy on-site monitoring of output.







Specifications:

- Maximum Total Current Capacity: 400 amps (maximum of 6 power supplies or modules).
- Digital Meter Accuracy: 1.6% +/- one digit.
- Circuit Breaker Voltage Rating: 80 VDC
- Digital meters, display, and status lights.
