OCZ StealthXStream 600W Power Supply

We apologize but this item is currently unavailable. Please feel free to browse our website for other available items.
Ocz Stealthxstream 600W Power Supply. Model: Ocz600sxs
  Enlarge
Ocz Stealthxstream 600W Power Supply. Model: Ocz600sxs
Ocz Stealthxstream 600W Power Supply. Model: Ocz600sxs
Ocz Stealthxstream 600W Power Supply. Model: Ocz600sxs
*Note this image is for descriptional purposes.
Actual product may vary.
Item Code PWROCZ600SXS600
Brand Ocz Technology
Model OCZ600SXS
Category House Brand Power Supplies

Description

OCZ StealthXStream OCZ600SXS 600W ATX12V / EPS12V SLI Ready Active PFC Power Supply.  The StealthXStream, kept supremely cool with a large 120mm fan, features a standard ATX power supply form factor resulting in a compact footprint to accommodate virtually all computer towers. With a sustained output of 600W and four +12V rails to provide uniform distribution of power, the StealthXStream is well-suited for and driving today's higher end systems. The rock solid StealthXStream is built to provide sufficient output to power dual GPU and CPU platforms, complete with two PCI-Express cables and a 4/8 CPU auxiliary connector which are wrapped in a flexible mesh promoting a tidy environment inside the case. The OCZ StealthXStream provides Universal Input and Active PFC (Power Factor Correction) to effectively regulate input voltage across worldwide power grids and maintain an economical, yet stable supply of power.

Manufacturer: OCZ
Part Number: OCZ600SXS

Specifications:

newegg  Compatible with the ATX12V v2.2 and EPS12V standards, the OCZ StealthXStream OCZ600SXS provides maximum power stability to drive the latest Intel and AMD               processors as well as other components for desktop and server computer systems.

newegg A maximum power of 600W delivers safe, reliable output for high-end PC systems.

newegg Delivering up to 83% (230V input) or 80% (115V input) efficiency, the OCZ StealthXStream OCZ600SXS power supply saves energy and may even reduce your electric bill!


Type
ATX12V / EPS12V

Maximum Power
600W

Fans
Internal 120mm fan

PFC
Active

Main Connector
20+4Pin

+12V Rails
4

PCI-Express Connector
1 x 6-Pin, 1 x 6+2-Pin

SATA Power Connector
3

SLI
Ready

Modular
No

Efficiency
80% @ 115V (Typical load)
83% @ 230V (Typical load)

Over Voltage Protection
Yes

Input Voltage
100 - 240 V

Input Frequency Range
50/60 Hz

Input Current
10 - 5A

Output
+3.3V@36A, +5V@30A, +12V1@18A, +12V2@18A, +12V3@18A, +12V4@18A, -12V@0.5A, +5VSB@3.0A

MTBF
>100,000 Hours

Approvals
CB, CE, CSA, UL, FCC

Connectors
1 x Main connector (20+4Pin)
1 x 12V(4/8Pin)
6 x peripheral
3 x SATA
2 x Floppy
2 x PCI-E
