PCCHIPS M825LU V7.5C WITH AMD PRO2600A+

PCChips M825LU V7.5C With AMD Pro2600A+ Processor (CPU) Motherboard Combo, Onboard Video Audio & LAN! Assembled & Tested!

Specifications:

Model: PCChips M825LU (V7.5C)

CPU: Pro 2600A+

CHIPSET: KM266/8235

FSB: 266/200MHz

VGA: Embedded ProSavage8 3D Graphics w/ 32M share memory

MEMORY: 2 x 184-pin DIMM sockets support two 2.5V DDR SDRAMs (DDR266/200)

EXPANSION SLOT:
1 x AGP 4X
2 x PCI slots
1 x CNR slot

AUDIO:
VIA VT1612A 2-channel audio Codec
Compliant with AC97 2.2 specification

LAN: VIA VT6103 10/100Mbps Fast Ethernet PHY

IDE: 2 x UltraDMA 133/100/66

REAR PANEL I/O:
1 x PS/2 keyboard
1 x PS/2 mouse
1 x Parallel Port
1 x Serial Port
1 x VGA port
4 x USB 2.0 Ports
1 x RJ 45 Port
1 x Audio I/O (Line-in, Line-out and Mic-in)

INTERNAL I/O CONNECTORS & HEADERS:
20-pin ATX power supply connector
4-pin ATX 12V power supply connector
1 x Floppy connector-support 360K~2.88M Byte, 3 Mode FDDs or LS120
1 x IrDA for SIR header
1 x USB header support additional 2 USB2.0 ports
1 x Front panel switch/LED header
1 x Speaker header

CPU / SYS FAN headers:
1 x CD in header
1 x Front panel audio header
1 x USB card reader header

SYSTEM BIOS:
AMI 2Mb Flash ROM
Supports Plug and Play 1.0A, APM 1.2, Multi Boot, DMI
Full support for ACPI revision 1.0 specification

FORM FACTOR: Micro-ATX Form Factor, 244*190mm
