Radeon RX Vega 56 DX12 8GB 2048-Bit ATX

Model

100420PSR

Interface

Interface

PCI Express 3.0

Chipset

Chipset Manufacturer

AMD

GPU Series

AMD Radeon RX VEGA Series

GPU

Radeon RX Vega 56

Core Clock

1208 MHz

Boost Clock

1512 MHz

Stream Processors

3584 Stream Processors

Memory

Effective Memory Clock

800 MHz, 1600 MHz Effective

Memory Size

8GB

Memory Interface

2048-Bit

Memory Type

HBM2

3D API

DirectX

DirectX 12

OpenGL

OpenGL 4.5

Ports

HDMI

1 x HDMI 2.0b

Multi-Monitor Support

4

DisplayPort

3 x DisplayPort 1.4

Details

Max Resolution

5120 x 2880

Eyefinity Support

Yes

CrossFireX Support

Yes

Virtual Reality Ready

Yes

Cooler

Double Fans

Operating Systems Supported

Windows 10
Windows 7

System Requirements

Power Consumption: 180W

System Requirement:
750-Watt Power Supply (Suggestion)
2 x 8-pin AUX Power Connector
CD-ROM or DVD-ROM drive for installing software
PCI Express 2.0 or higher version based PC is required with one X16 lane graphics slot available on the motherboard in order for the card to be compatible with

Power Connector

2 x 8-Pin
