Samsung 15.6" TFT LED LCD Screen Panel

Samsung LTN156AT24-T01 is a color active matrix TFT (Thin Film Transistor) liquid crystal display (LCD) that uses amorphous silicon TFT as switching devices. This model is composed of a TFT LCD panel, a driver circuit and a backlight unit. The resolution of a 15.6" contains 1,366 x 768 pixels and can display up to 262,144 colors. 6 O'clock direction is the Optimum viewing angle.


Features:

• Thin and light weight
• High contrast ratio, high aperture structure
• 1366 x 768 pixels resolution (16:9)
• Fast Response Time
• Low power consumption
• LED BLU Structure
• DE (Data enable) only mode
• 3.3V LVDS Interface
• On board EDID chip
• Pb-free product


Specifications:

Display area: 344.232 (H) x 193.536 (V) (15.6”diagonal)
Driver element: a-Si TFT active matrix
Number of pixel: 1366 x 768 pixel
Pixel Format: RGB vertical stripe
Pixel pitch: 0.252 (H) x 0.252 (V) (TYP.) mm
Surface treatment:  Haze 0 Hardness 3H
Display colors: 262,144 6 Bit
Backlight: WLED


** Please Note, This item was removed from a working unit, it may have minor scuffs and scratches, but is fully operational and functions as intended!
