Samsung 17.3" TFT LED LCD Screen Panel

Samsung LTN173KT01-P06 is a color active matrix TFT (Thin Film Transistor) liquid crystal display (LCD) that uses amorphous silicon TFT as switching devices. This model is composed of a TFT LCD panel, a driver circuit and a backlight system. The resolution of a 17.3" contains 1600 x 900 pixels and can display up to 262,144 colors. 6 O'clock direction is the Optimum viewing angle.

** Please Note, This item was removed from a working unit, it may have minor scuffs and scratches, but is fully operational and functions as intended!


FEATURES:

• Thin and light weight
• High contrast ratio, high aperture structure
• 1600 x 900 pixels resolution (16:9)
• Fast Response Time
• Low power consumption
• LED BLU Structure
• DE (Data enable) only mode
• 3.3V LVDS Interface
• On board EDID chip
• Pb-free product

Specifications:

Surface treatment: Haze 0, Hardness 3H Glare
Display Mode: Normally white
Pixel pitch: 0.2388 (H) x 0.2388 (V) (TYP.) mm
Pixel arrangement: RGB vertical stripe
Number of pixel: 1600 x 900 pixel 16 : 9
Display colors: 262,144
Driver element: a-Si TFT active matrix
Display area: 382.08 (H) x 214.92 (V) (17.3 ”diagonal) mm
