Samsung 22" LTM220M1-L01 Touch Display
We apologize but this item is currently unavailable. Please feel free to browse our website for other available items.
Item Code LTPLCDLTM220M1L
Brand Samsung
Model LTM220M1-L01 (T7)
Category Laptop Lcd Screens & Digitizers
Description
Samsung LTM220M1-L01 is a color active matrix liquid crystal Touchscreen Display (LCD) that uses amorphous silicon TFT (Thin Film Transistor) as switching components. This model is composed of a TFT LCD panel, a driver circuit and a back light unit. The resolution of a 22” is 1680 x 1050 and this model can display up to 16.7 millions colors.
Samsung Part Number: LTM220M1-L01 (T7)
Compatible Part Numbers: LJ96-04132F
Features:
High contrast ratio, high aperture structure
TN (Twisted Nematic) mode
Wide Viewing Angle
High speed response
WSXGA+ (1680 x 1050 pixels) resolution
Low power consumption
DE (Data Enable) only mode
LVDS (Low Voltage Differential Signaling) interface (2pixel/clock)
Compact Size Design
RoHS, TCO 03’ compliance
