SEAGATE BARRACUDA 7200.9 ST3160212A HDD

Seagate Barracuda 7200.9 ST3160212A 160 GB100 MBps 7200 rpm  Internal hard drive. The Seagate Barracuda 7200.9 is the industry's most comprehensive 3.5-inch drive, providing leading technology targeted at PATA servers, mainstream and high-performance PCs/workstations and media PCs.Barracuda 7200.9 is a member of the Seagate 3.5-inch family of high-capacity desktop drives targeted at mainstream and high-performance PCs and advanced storage applications. The product enables system builders to qualify one family of drives from a premier provider for a wide range of storage applications.

Specifications:

Storage Capacity: 160 GB
Hard Drive Interface: 1 x Ultra ATA/100 (ATA-6) IDE/EIDE
Maximum External Data Transfer Rate: 100 MBps
Start/Stop Cycles: 50000
Latency: 4.16 ms Average
Seek Time: 11 ms Average
Buffer: 2 MB
Sound Emission: 25 dB Idle (Typical)
Rotational Speed: 7200 rpm
Product Series: 7200.9
Product Type: Hard Drive
Manufacturer Part Number: ST3160212A
Certifications & Standards: RoHS Compliant S.M.A.R.T
Compatible Drive Bay Width: 3.5"
Width: 0.46"
Form Factor: Internal
Depth: 5.79"
Height: 1.03"
Input Voltage: 5 VDC 5%
12 V DC 10%
Power Consumption: 8.16W Seek 6.95W Idle 329 mW Standby
Input Current: 2.61 A Typical @ 12 V DC Operating
Heads: 16 Logical
Cylinders: 16383
Platform Support: PC
Storage Capacity: 160 GB
Sectors Per Track: 63
Bytes Per Sector: 512
